Headlights circuit, w/ hid headlamps w/ high equipment for Volkswagen Bora III (2012-2018)

BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 29 FUSE PANEL B GRY WIRE GRY/BLK WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT FRONT FOG LAMP/ CORNERING LAMP BULB ORG/ WIRE ORG/BRN WIRE ORG/GRN WIRE RED/YEL WIRE RIGHT ADAPTIVE CORNERING LAMP MOTOR RIGHT DRL, POSITION LAMP CONTROL MODULE RIGHT DRL, POSITION LAMP LED MODULE RIGHT FRONT FOG LAMP/ CORNERING LAMP BULB RIGHT FRONT HEADLAMP RIGHT FRONT SIDE MARKER LAMP BULB RIGHT FRONT TURN SIGNAL LAMP BULB RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR RIGHT HEADLAMP POWER OUTPUT MODULE RIGHT HID HEADLAMP BULB RIGHT HID HEADLAMP CONTROL MODULE RIGHT LOW BEAM HEADLAMP REFLECTOR MOTOR RIGHT SWIVEL POSITION MODULE SENSOR RIGHT VARIABLE HEADLAMP POSITIONING MOTOR RIGHT VARIABLE HEADLAMP POSITIONING MOTOR SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE

BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRL IND FUSE 11 FUSE 12 FUSE 14 FUSE 15 FUSE PANEL C GRY WIRE GRY/BLK WIRE GRY/WHT WIRE GRY/YEL WIRE HIGH BEAM IND HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE LEFT ADAPTIVE CORNERING LAMP MOTOR LEFT DRL, POSITION LAMP CONTROL MODULE LEFT DRL, POSITION LAMP LED MODULE LEFT FRONT HEADLAMP LEFT FRONT SIDE MARKER LAMP BULB LEFT FRONT TURN SIGNAL LAMP BULB LEFT HEADLAMP POWER OUTPUT MODULE LEFT HID HEADLAMP BULB LEFT HID HEADLAMP CONTROL MODULE LEFT LOW BEAM HEADLAMP REFLECTOR MOTOR LEFT SWIVEL POSITION MODULE SENSOR LEFT VARIABLE HEADLAMP POSITIONING MOTOR LEFT VARIABLE HEADLAMP POSITIONING MOTOR SENSOR ORG/ WIRE PARKING BRAKE INDICATOR LAMP SWITCH VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE

AUTOMATIC LIGHT CONTROL INDICATOR LAMP BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/YEL WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CORNERING LAMP, HEADLAMP RANGE CONTROL MODULE FOG INDICATOR LAMP FOG LAMP SWITCH FUSE 13 FUSE 23 FUSE PANEL C GRN WIRE GRY WIRE GRY/WHT WIRE GRY/YEL WIRE HEADLAMP SWITCH ILLUMINATION BULB HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT REAR LEVEL CONTROL SYSTEM SENSOR LIGHT SWITCH ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE REAR FOG LAMP SWITCH RED WIRE VIO WIRE WHT WIRE WHT/BLK WIRE WHT/YEL WIRE YEL WIRE
