Electronic power steering circuit for Volkswagen Bora III (2012-2018)
Electronic power steering circuit
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRO- MECHANICAL POWER STEERING INDICATOR LAMP
ELECTRO- MECHANICAL POWER STEERING MOTOR
FUSE 14
FUSE 3
FUSE PANEL A
FUSE PANEL C
GRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
ORG/BLK WIRE
ORG/BRN WIRE
POWER STEERING CONTROL MODULE
RED WIRE
STEERING TORQUE/ STEERING ANGLE SENSOR
VIO WIRE
WHT WIRE
YEL WIRE
