Volkswagen Bora III (2012-2018) w/ automatic mirror adjustment w/o automatic mirror adjustment Wiring diagram
This page shows the only wiring diagram for the component.w/ automatic mirror adjustment w/o automatic mirror adjustment, which is found in the car Volkswagen Bora III (2012-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ automatic mirror adjustment w/o automatic mirror adjustment (1 of 1)
ADJUSTMENT MOTOR
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR REAR VIEW MIRROR
DRIVER EXTERIOR REAR VIEW MIRROR FOLDING MOTOR
EXTERIOR REAR VIEW MIRROR HEATER SWITCH
EXTERIOR REAR VIEW MIRROR SWITCH
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR FOLDING MOTOR
FUSE 45
FUSE 46
FUSE PANEL C
GRY WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HEATER
HORIZONTAL POSITION SENSOR
HOT AT ALL TIMES
MIRROR ADJUSTMENT ILLUMINATION SWITCH BULB
MIRROR ADJUSTMENT SWITCH
MIRROR FOLDING SWITCH
MIRROR SELECTOR SWITCH
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/YEL WIRE
TURN SIGNAL BULB
VERTICAL POSITION SENSOR
VIO WIRE
W/ AUTOMATIC MIRROR ADJUSTMENT W/O AUTOMATIC MIRROR ADJUSTMENT
W/O MIRROR ADJUSTMENT
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Power mirrors circuit, w/ high equipment -> W/ AUTOMATIC MIRROR ADJUSTMENT W/O AUTOMATIC MIRROR ADJUSTMENT
