Volkswagen Bora III (2012-2018) tiptronic upshift button on steering wheel Wiring diagram
This page shows the only wiring diagram for the component.tiptronic upshift button on steering wheel, which is found in the car Volkswagen Bora III (2012-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tiptronic upshift button on steering wheel (1 of 1)
AIR BAG SPIRAL SPRING/ RETURN SPRING (W/ SLIP RING)
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
FUSE 14
FUSE 27
FUSE PANEL C
GRN WIRE
GRY WIRE
HORNS SYSTEM
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
RED WIRE
RIGHT MULTI-FUNCTION BUTTONS ON STEERING WHEEL
STEERING ANGLE SENSOR
SUPPLEMENTAL RESTRAINTS SYSTEM
TIPTRONIC DOWNSHIFT BUTTON ON STEERING WHEEL
TIPTRONIC UPSHIFT BUTTON ON STEERING WHEEL
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
W/ HIGH EQUIPMENT
W/ LOW EQUIPMENT
YEL WIRE
Go to component -> Steering column electronic systems control module circuit (2 of 2) -> TIPTRONIC UPSHIFT BUTTON ON STEERING WHEEL
