Volkswagen Bora III (2012-2018) steering torque/ steering angle sensor Wiring diagram
This page shows the only wiring diagram for the component.steering torque/ steering angle sensor, which is found in the car Volkswagen Bora III (2012-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering torque/ steering angle sensor (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRO- MECHANICAL POWER STEERING INDICATOR LAMP
ELECTRO- MECHANICAL POWER STEERING MOTOR
FUSE 14
FUSE 3
FUSE PANEL A
FUSE PANEL C
GRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
ORG/BLK WIRE
ORG/BRN WIRE
POWER STEERING CONTROL MODULE
RED WIRE
STEERING TORQUE/ STEERING ANGLE SENSOR
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Electronic power steering circuit -> STEERING TORQUE/ STEERING ANGLE SENSOR
