Volkswagen Bora III (2012-2018) right turn signal ind lamp Wiring diagram
This page shows the only wiring diagram for the component.right turn signal ind lamp, which is found in the car Volkswagen Bora III (2012-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right turn signal ind lamp (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/YEL WIRE
BRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
EMERGENCY FLASHER BUTTON, INDICATOR LAMP
FUSE 23
FUSE 29
FUSE PANEL B
FUSE PANEL C
GRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/BLK WIRE
GRY/RED WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HIGH-MOUNTED BRAKE LAMP
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
LEFT CORNERING LAMP, LEFT FRONT FOG LAMP
LEFT FRONT HEADLAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT POSITION LAMP
LEFT TURN SIGNAL IND LAMP
LICENSE PLATE LIGHT
LIGHT SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT CORNERING LAMP, RIGHT FRONT FOG LAMP
RIGHT FRONT HEADLAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT POSITION LAMP
RIGHT TURN SIGNAL IND LAMP
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
W/O HID
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, w/ high equipment (1 of 4) -> RIGHT TURN SIGNAL IND LAMP
