Volkswagen Bora III (2012-2018) right center reading lamp Wiring diagrams
This page contains all the electrical diagrams for the component. right center reading lamp, in which he is found in the car Volkswagen Bora III (2012-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right center reading lamp (1 of 2)
Go to component -> Courtesy lamps circuit, w/ high equipment (2 of 3) -> RIGHT CENTER READING LAMP
Wiring diagram right center reading lamp (2 of 2)
Go to component -> Courtesy lamps circuit, w/ low equipment (2 of 3) -> RIGHT CENTER READING LAMP
