Volkswagen Bora III (2012-2018) rear lid lock/ alarm/central locking switch Wiring diagram
This page shows the only wiring diagram for the component.rear lid lock/ alarm/central locking switch, which is found in the car Volkswagen Bora III (2012-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear lid lock/ alarm/central locking switch (1 of 1)
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
DRIVER VANITY MIRROR LAMP CONTACT SWITCH
DRIVER'S VANITY MIRROR LAMP
FRONT PASSENGER VANITY MIRROR LAMP
FRONT PASSENGER VANITY MIRROR LAMP CONTACT SWITCH
GLOVE COMPARTMENT LAMP
GLOVE COMPARTMENT LAMP SWITCH
LUGGAGE COMPARTMENT LAMP
REAR LID LOCK UNIT
REAR LID LOCK/ ALARM/CENTRAL LOCKING SWITCH
RED/BLU WIRE
RED/WHT WIRE
Go to component -> Courtesy lamps circuit, w/ high equipment (3 of 3) -> REAR LID LOCK/ ALARM/CENTRAL LOCKING SWITCH
