Volkswagen Bora III (2012-2018) left rear door power window switch Wiring diagrams
This page contains all the electrical diagrams for the component. left rear door power window switch, in which he is found in the car Volkswagen Bora III (2012-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left rear door power window switch (1 of 2)
BLU/YEL WIRE
BRN WIRE
CHILD SAFETY LOCK- ACTIVATED- INDICATOR LAMP
COMPUTER DATA LINES SYSTEM
DRIVER SIDE POWER WINDOW SWITCH
DRIVER'S DOOR CONTROL MODULE
EXCEPT HYBRID
EXTERIOR REAR VIEW MIRROR SWITCH
GRN WIRE
GRY WIRE
LEFT REAR DOOR CONTROL MODULE
LEFT REAR DOOR POWER WINDOW SWITCH
MIRROR ADJUSTMENT SWITCH ILLUMINATION BULB
ORG/BRN WIRE
ORG/GRN WIRE
PRESSURE EQUALIZATION, REAR LID REMOTE RELEASE BUTTON
REAR CENTER INTERIOR LOCKING SWITCH
REAR LID REMOTE RELEASE BUTTON
RED/BLK WIRE
RED/YEL WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
Go to component -> Instrument illumination circuit, w/ high equipment (4 of 4) -> LEFT REAR DOOR POWER WINDOW SWITCH
Wiring diagram left rear door power window switch (2 of 2)
BRN WIRE
CHILD SAFETY LOCK- ACTIVATED- INDICATOR LAMP
DRIVER DOOR AMBIENT LIGHTING BULB
DRIVER SIDE POWER WINDOW SWITCH
DRIVER'S DOOR CONTROL MODULE
EMERGENCY FLASHER BUTTON, INDICATOR LAMP
FRONT PASSENGER DOOR AMBIENT LIGHTING BULB
FRONT PASSENGER INTERIOR LOCKING BUTTON
GRN/RED WIRE
GRY WIRE
LEFT REAR DOOR POWER WINDOW SWITCH
PARKING AID INDICATOR LAMP
RED/YEL WIRE
RIGHT REAR DOOR CONTROL MODULE
RIGHT REAR DOOR POWER WINDOW SWITCH
VIO WIRE
VIO/WHT WIRE
WHT/BLU WIRE
Go to component -> Instrument illumination circuit, w/ low equipment (2 of 3) -> LEFT REAR DOOR POWER WINDOW SWITCH
