Volkswagen Bora III (2012-2018) hood open indicator lamp Wiring diagrams
This page contains all the electrical diagrams for the component. hood open indicator lamp, in which he is found in the car Volkswagen Bora III (2012-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
hood open indicator lamp wiring diagram (1 of 4)
ANTI-THEFT IMMOBILIZER CONTROL MODULE
ANTI-THEFT IMMOBILIZER INDICATOR LAMP
ANTI-THEFT IMMOBILIZER READER COIL
BLK WIRE
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR AJAR INDICATOR LAMP
DRIVER'S INTERIOR LOCKING BUTTON
FRONT PASSENGER INTERIOR LOCKING BUTTON
GRY WIRE
HOOD OPEN INDICATOR LAMP
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
REAR CENTER INTERIOR LOCKING SWITCH
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit, w/ low equipment (3 of 3) -> HOOD OPEN INDICATOR LAMP
hood open indicator lamp wiring diagram (2 of 4)
2.0L
2.0L TURBO
ABS INDICATOR LAMP
AIR BAG INDICATOR LAMP
ANTI-THEFT IMMOBILIZER CONTROL MODULE
ANTI-THEFT IMMOBILIZER SYSTEM INDICATOR LAMP GLOW PLUG INDICATOR LAMP
ANTI-THEFT SYSTEM
ASR/ESP INDICATOR LAMP
BLK WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BRAKE PAD WEAR INDICATOR LAMP
BRAKE SYSTEM INDICATOR LAMP
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL INDICATOR LAMP
DAYTIME RUNNING LAMP INDICATOR LAMP
DOOR AJAR INDICATOR LAMP
ELECTRICAL DRIVE INDICATOR LAMP
ELECTRO- MECHANICAL POWER STEERING INDICATOR LAMP
ELECTRONIC POWER CONTROL MALFUNCTION INDICATOR LAMP
ENGINE COOLANT LEVEL SENSOR
ENGINE COOLANT LEVEL/TEMPERATURE INDICATOR LAMP
ENGINE COOLANT TEMPERATURE GAUGE
ENGINE ELECTRONICS INDICATOR LAMP
FUEL GAUGE
FUEL LEVEL SENSOR, TRANSFER FUEL PUMP
FUEL LEVEL SENSOR/TRANSFER FUEL PUMP
FUEL PUMP CONTROL MODULE
FUSE 14
FUSE 3
FUSE PANEL C
GENERATOR INDICATOR LAMP
GRY/YEL WIRE
HIGH BEAM INDICATOR LAMP
HOOD OPEN INDICATOR LAMP
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
LAMP FAILURE INDICATOR LAMP
LEFT TURN SIGNAL INDICATOR LAMP
LOW FUEL LEVEL INDICATOR LAMP
MALFUNCTION INDICATOR LAMP
MULTI-FUNCTION INDICATOR
OIL LEVEL INDICATOR LAMP
OIL PRESSURE INDICATOR LAMP
OUTSIDE AIR TEMPERATURE SENSOR
RED WIRE
RIGHT STEERING COLUMN SWITCH
RIGHT TURN SIGNAL INDICATOR LAMP
SEAT BELT INDICATOR LAMP FUEL FILLER DOOR LOCK INDICATOR LAMP
SHIFT LOCK INDICATOR LAMP
SPEEDOMETER
TACHOMETER
TIRE PRESSURE MONITORING DISPLAY INDICATOR LAMP
VIO WIRE
VIO/BLK WIRE
VIO/RED WIRE
VIO/WHT WIRE
W/ MULTI-FUNCTION DISPLAY
WARNING BUZZER, TONE
WHT WIRE
WINDSHIELD WASHER FLUID LEVEL INDICATOR LAMP
WINDSHIELD WASHER FLUID LEVEL SENSOR
YEL WIRE
Go to component -> Instrument cluster circuit, w/ high equipment (1 of 2) -> HOOD OPEN INDICATOR LAMP
hood open indicator lamp wiring diagram (3 of 4)
2.0L 2.0L TURBO DIESEL 1.8L TURBO 2.0L, 1.8L TURBO
ABS INDICATOR LAMP
AIR BAG INDICATOR LAMP
ANTI-THEFT IMMOBILIZER CONTROL MODULE
ANTI-THEFT IMMOBILIZER SYSTEM INDICATOR LAMP
ANTI-THEFT SYSTEM
ASR/ESP INDICATOR LAMP
BLK WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BRAKE PAD WEAR INDICATOR LAMP
BRAKE SYSTEM INDICATOR LAMP
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL INDICATOR LAMP
DAYTIME RUNNING LAMP INDICATOR LAMP
DOOR AJAR INDICATOR LAMP
ELECTRO- MECHANICAL POWER STEERING INDICATOR LAMP
ELECTRONIC POWER CONTROL MALFUNCTION INDICATOR LAMP
ENGINE COOLANT LEVEL SENSOR
ENGINE COOLANT LEVEL/TEMPERATURE INDICATOR LAMP
ENGINE COOLANT TEMPERATURE GAUGE
ENGINE ELECTRONICS INDICATOR LAMP
FUEL FILLER DOOR LOCK INDICATOR LAMP
FUEL GAUGE
FUEL LEVEL SENSOR, TRANSFER FUEL PUMP
FUEL PUMP CONTROL MODULE/ FUEL DELIVERY UNIT
FUSE 14
FUSE 3
FUSE PANEL C
GENERATOR INDICATOR LAMP
GLOW PLUG INDICATOR LAMP
GRN WIRE
GRY WIRE
GRY/YEL WIRE
HIGH BEAM INDICATOR LAMP
HOOD OPEN INDICATOR LAMP
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
LAMP FAILURE INDICATOR LAMP
LEFT TURN SIGNAL INDICATOR LAMP
LOW FUEL LEVEL INDICATOR LAMP
MALFUNCTION INDICATOR LAMP
MULTI-FUNCTION INDICATOR
OIL LEVEL INDICATOR LAMP
OIL LEVEL THERMAL SENSOR
OIL PRESSURE INDICATOR LAMP
OUTSIDE AIR TEMPERATURE SENSOR
REAR FOG LAMP INDICATOR LAMP
RED WIRE
RIGHT STEERING COLUMN SWITCH
RIGHT TURN SIGNAL INDICATOR LAMP
SEAT BELT INDICATOR LAMP
SHIFT LOCK INDICATOR LAMP
SPEEDOMETER
TACHOMETER
TIRE PRESSURE MONITORING DISPLAY INDICATOR LAMP
VIO WIRE
VIO/BLK WIRE
VIO/RED WIRE
VIO/WHT WIRE
W/ MULTI-FUNCTION DISPLAY
WARNING BUZZER, TONE
WHT WIRE
WINDSHIELD WASHER FLUID LEVEL INDICATOR LAMP
WINDSHIELD WASHER FLUID LEVEL SENSOR
YEL WIRE
Go to component -> Instrument cluster circuit, w/ low equipment (1 of 2) -> HOOD OPEN INDICATOR LAMP
hood open indicator lamp wiring diagram (4 of 4)
ANTI-THEFT IMMOBILIZER CONTROL MODULE
ANTI-THEFT IMMOBILIZER INDICATOR LAMP
ANTI-THEFT IMMOBILIZER READER COIL
BLK WIRE
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR AJAR INDICATOR LAMP
DRIVER'S INTERIOR LOCKING BUTTON
FRONT PASSENGER INTERIOR LOCKING BUTTON
GRY WIRE
HOOD OPEN INDICATOR LAMP
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
REAR CENTER INTERIOR LOCKING SWITCH
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit, w/ low equipment (3 of 3) -> HOOD OPEN INDICATOR LAMP
