Volkswagen Bora III (2012-2018) headlamp range/ cornering lamp control module Wiring diagram
This page shows the only wiring diagram for the component.headlamp range/ cornering lamp control module, which is found in the car Volkswagen Bora III (2012-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram headlamp range/ cornering lamp control module (1 of 1)
1.4L TURBO HYBRID 2.0L TURBO 2.0L
1.4L TURBO HYBRID 2.0L TURBO, 2.0L TURBO DIESEL
ABS CONTROL MODULE (IF EQUIPPED)
AIR BAG CONTROL MODULE
AMPLIFIER
AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR
BLU/YEL WIRE
CELL PHONE OPERATING ELECTRONICS CONTROL MODULE
COMPASS MAGNETIC FIELD SENSOR
DSG TRANSMISSION MECHATRONIC
ELECTRIC DRIVE POWER, CONTROL ELECTRONICS
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
ENGINE CONTROL MODULE
GRY/WHT WIRE
HEADLAMP RANGE/ CORNERING LAMP CONTROL MODULE
HYBRID BATTERY UNIT
LEFT FRONT HEADLAMP (W/ HID)
MULTIMEDIA SYSTEM CONTROL MODULE
NCA WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/VIO WIRE
PARKING AID CONTROL MODULE
POWER STEERING CONTROL MODULE
RADIO
RADIO/ NAVIGATION DISPLAY UNIT CONTROL MODULE
RIGHT FRONT HEADLAMP
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
TELEPHONE TRANSCEIVER
TRANSMISSION CONTROL MODULE
VEHICLE POSITIONING SYSTEM CONTROL MODULE
W/ 6 SPEED TRANSMISSION
W/ HID
W/O ESP W/ ESP
Go to component -> Computer data lines circuit, w/ high equipment (2 of 2) -> HEADLAMP RANGE/ CORNERING LAMP CONTROL MODULE
