Volkswagen Bora III (2012-2018) electro- mechanical power steering indicator lamp Wiring diagrams
This page contains all the electrical diagrams for the component. electro- mechanical power steering indicator lamp, in which he is found in the car Volkswagen Bora III (2012-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram electro- mechanical power steering indicator lamp (1 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRO- MECHANICAL POWER STEERING INDICATOR LAMP
ELECTRO- MECHANICAL POWER STEERING MOTOR
FUSE 14
FUSE 3
FUSE PANEL A
FUSE PANEL C
GRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
ORG/BLK WIRE
ORG/BRN WIRE
POWER STEERING CONTROL MODULE
RED WIRE
STEERING TORQUE/ STEERING ANGLE SENSOR
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Electronic power steering circuit -> ELECTRO- MECHANICAL POWER STEERING INDICATOR LAMP
