Supplemental restraints circuit for Volkswagen Beetle A5 (2011-2019)

Supplemental restraints circuit (1 of 3)

Beetle Volkswagen A5 (2011-2019): Supplemental restraints circuit (1 of 3)

Get access

AIR BAG CONTROL MODULE BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER ROLLOVER PROTECTION SOLENOID DRIVER SEAT BELT TENSIONER IGNITER 1, DRIVER BELT FORCE LIMITER DRIVER'S SEAT BELT SWITCH DRIVER'S SEAT POSITION SENSOR FRONT PASSENGER ROLLOVER PROTECTION SOLENOID FRONT PASSENGER SEAT POSITION SENSOR FUSE 9 FUSE PANEL C GRY WIRE GRY/BLK WIRE GRY/RED WIRE HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED NCA WIRE RED WIRE VIO WIRE WHT WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/RED WIRE

Supplemental restraints circuit (2 of 3)

Beetle Volkswagen A5 (2011-2019): Supplemental restraints circuit (2 of 3)

Get access

BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE DRIVER THORAX AIR BAG IGNITER FRONT PASSENGER AIR BAG DISABLED INDICATOR LAMP FRONT PASSENGER AIR BAG IGNITER 1, 2 FRONT PASSENGER SEAT BELT SWITCH FRONT PASSENGER THORAX AIR BAG IGNITER GRY WIRE IGNITIER 1 IGNITIER 2 NCA WIRE PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE PASSENGER OCCUPANT DETECTION SYSTEM PRESSURE SENSOR RED WIRE RED/YEL WIRE VIO WIRE WHT WIRE WHT/YEL WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE

Supplemental restraints circuit (3 of 3)

Beetle Volkswagen A5 (2011-2019): Supplemental restraints circuit (3 of 3)

Get access

AIR BAG CONTROL MODULE AIR BAG INDICATOR LAMP AIR BAG SPIRAL SPRING/RETURN SPRING W/ SLIP RING BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER FRONT AIR BAG CRASH SENSOR DRIVER SIDE AIR BAG CRASH SENSOR DRIVER THORAX AIR BAG CRASH SENSOR DRIVER'S AIR BAG IGNITER FRONT PASSENGER SIDE AIR BAG CRASH SENSOR FRONT PASSENGER THORAX AIRBAG CRASH SENSOR GRN WIRE GRY WIRE GRY/BLK WIRE HATCHBACK INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE NCA WIRE ORG/BLK WIRE ORG/BRN WIRE PASSENGER SIDE FRONT AIR BAG CRASH SENSOR RED WIRE RED/YEL WIRE SEAT BELT INDICATOR LAMP STEERING COLUMN ELECTRONICS CONTROL MODULE VIO/GRN WIRE VIO/YEL WIRE WHT WIRE YEL WIRE YEL/BLU WIRE
