2.0l turbo diesel, starting circuit for Volkswagen Beetle A5 (2011-2019)
2.0l turbo diesel, starting circuit (1 of 2)
BATTERY
BLK WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLU WIRE
BLU/VIO WIRE
BRN WIRE
CHARGING CIRCUIT
COMPUTER DATA LINES SYSTEM
DIRECT SHIFT GEAR BOX (DSG) TRANSMISSION MECHATRONIC
ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
ENGINE CONTROL MODULE
FUSE 20
FUSE 22
FUSE PANEL C
HOT AT ALL TIMES
IN PLENUM CHAMBER)
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/VIO WIRE
RED/YEL WIRE
SELECTOR LEVER PARK POSITION LOCK SWITCH
STARTER
STARTER RELAY 2
TERMINAL 50 POWER SUPPLY RELAY
TIPTRONIC SWITCH
TRANSMISSION CONTROL MODULE
VIO WIRE
VIO/BLU WIRE
VIO/GRN WIRE
YEL WIRE
YEL/BLU WIRE
2.0l turbo diesel, starting circuit (2 of 2)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLU WIRE
BLU/VIO WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONVERTER BOX
FUSE 25
FUSE PANEL B
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGNITION SWITCH KEY LOCK SOLENOID
IGNITION/STARTER SWITCH
INSTRUMENT CLUSTER CONTROL MODULE INSTRUMENT CLUSTER
ORG/ WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
START SYSTEM BUTTON
TERMINAL 15 POWER SUPPLY RELAY
TERMINAL 15 POWER SUPPLY RELAY 2
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/BLU WIRE
VIO/GRN WIRE
YEL WIRE
