Radio circuit, w/o rns 510 & amplifier for Volkswagen Beetle A5 (2011-2019)
Radio circuit, w/o rns 510 & amplifier (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
EXTERNAL AUDIO SOURCE CONNECTION
FUSE 13
FUSE PANEL B
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT BASS SPEAKER
LEFT FRONT TREBLE SPEAKER
LEFT REAR WINDOW ANTENNA IMPEDANCE CONVERTER
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED/YEL WIRE
TELEPHONE MICROPHONE (IN FRONT INTERIOR LAMP)
WHT WIRE
WHT/RED WIRE
YEL WIRE
Radio circuit, w/o rns 510 & amplifier (2 of 2)
ANTENNA
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
GPS ANTENNA
GRN WIRE
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT REAR BASS SPEAKER
LEFT REAR TREBLE SPEAKER
NCA WIRE
ORG/ WIRE
RADIO ANTENNA 2
RED/VIO WIRE
RED/WHT WIRE
RIGHT FRONT BASS SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR BASS SPEAKER
RIGHT REAR TREBLE SPEAKER
RIGHT REAR WINDOW ANTENNA IMPEDANCE CONVERTER
ROOF ANTENNA
USB CONNECTION 1 (IF EQUIPPED)
W/ DIGITAL RADIO
W/ NAVIGATION
WHT/RED WIRE
