Power seats circuit for Volkswagen Beetle A5 (2011-2019)
Power seats circuit
A/C CONTROL MODULE
AUTOMATIC A/C
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CLIMATRONIC CONTROL MODULE
DRIVER BACKREST HEATING ELEMENT
DRIVER HEATED SEAT ADJUSTER
DRIVER HEATED SEAT TEMPERATURE SENSOR/HEATING ELEMENT
FRONT PASSENGER BACKREST HEATING ELEMENT
FRONT PASSENGER HEATED SEAT ADJUSTER
FRONT PASSENGER HEATED SEAT TEMPERATURE SENSOR/HEATING ELEMENT
FRONT SEAT HEATING CONTROL MODULE
FUSE 50
FUSE PANEL C
GRN WIRE
HOT AT ALL TIMES
MANUAL A/C
RED WIRE
RED/YEL WIRE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/BLU WIRE
W/ AUXILIARY HEATER
WHT WIRE
YEL WIRE
