Power mirrors circuit for Volkswagen Beetle A5 (2011-2019)
Power mirrors circuit
ADJUSTMENT MOTORS
BLK/GRN WIRE
BLK/RED WIRE
BLU/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
DEFOGGER SYSTEM
DRIVER EXTERIOR REAR VIEW MIRROR ASSEMBLY
EXTERIOR REAR VIEW MIRROR SWITCH
FRONT PASSENGER'S EXTERIOR REAR VIEW MIRROR ASSEMBLY
FUSE 13
FUSE PANEL C
HEATER
HOT W/ TERMINAL 15 POWER SUPPLY RELAY 2 ENERGIZED
MIRROR ADJUSTING SWITCH
MIRROR ADJUSTMENT SWITCH ILLUMINATION
MIRROR HEATING SWITCH
MIRROR SELECTOR SWITCH
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
R-O-L
TURN SIGNAL
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/BLK WIRE
VIO/BRN WIRE
WHT WIRE
