Navigation circuit, w/ rns 510 w/o amplifier for Volkswagen Beetle A5 (2011-2019)

AUXILIARY VIDEO/ AUDIO CONNECTION MODULE BLK WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM EXTERNAL AUDIO SOURCE CONNECTION FUSE 13 FUSE PANEL B GPS ANTENNA GRN WIRE GRN/BLK WIRE GRY WIRE HATCHBACK HOT AT ALL TIMES LEFT FRONT BASS SPEAKER LEFT FRONT TREBLE SPEAKER MULTIMEDIA INTERFACE CIRCUIT NAVIGATION SYSTEM NCA WIRE ORG/BRN WIRE ORG/GRN WIRE RADIO (OR) RADIO/NAVIGATION DISPLAY UNIT CONTROL MODULE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT ANTENNA MODULE TELEPHONE MICROPHONE VIO/GRN WIRE VIO/YEL WIRE W/ EMERGENCY CALL MODULE W/ MULTI- MEDIA W/ NAVIGATION SYSTEM CONTROL MODULE W/O NAVIGATION SYSTEM CONTROL MODULE W/O EMERGENCY CALL MODULE W/O MULTI- MEDIA WHT WIRE WHT/BLK WIRE YEL WIRE

ANTENNA BLK WIRE BRN WIRE BRN/BLK WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE FM FREQUENCY FILTER (NEGATIVE WIRE) FM FREQUENCY FILTER (POSITIVE WIRE) GRY WIRE GRY/BLU WIRE GRY/YEL WIRE HATCHBACK LEFT REAR BASS SPEAKER LEFT REAR TREBLE SPEAKER NCA WIRE RADIO ANTENNA RADIO ANTENNA 2 REAR WINDOW DEFOGGER RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT REAR BASS SPEAKER RIGHT REAR TREBLE SPEAKER VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/GRN WIRE VIO/YEL WIRE WHT WIRE YEL WIRE

ANTENNA BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA GRN WIRE GRY WIRE LEFT ANTENNA MODULE LINES SYSTEM NAVIGATION SYSTEM CONTROL MODULE (HATCHBACK) (UNDER DRIVER SEAT) NCA WIRE ORG/ WIRE ORG/BRN WIRE ORG/GRN WIRE RADIO (OR) RADIO/NAVIGATION DISPLAY UNIT CONTROL MODULE RADIO ANTENNA 2 REAR VIEW CAMERA RED WIRE RED/YEL WIRE RIGHT ANTENNA MODULE SATELLITE ANTENNA SATELLITE TUNER ANTENNA TELEPHONE/ NAVIGATION SYSTEM SPEAKER VIO/GRN WIRE VIO/YEL WIRE W/ REAR VIEW CAMERA W/O REAR VIEW CAMERA WHT WIRE YEL WIRE
