Navigation circuit, w/ rns 510 & amplifier for Volkswagen Beetle A5 (2011-2019)

ANTENNA AUXILIARY VIDEO/ AUDIO CONNECTION MODULE BLK WIRE BLU WIRE BRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM EXTERNAL AUDIO SOURCE CONNECTION FM FREQUENCY FILTER (NEGATIVE WIRE) FUSE 13 FUSE PANEL B GPS ANTENNA GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLU WIRE GRY/YEL WIRE HATCHBACK HOT AT ALL TIMES MULTIMEDIA INTERFACE CIRCUIT NAVIGATION SYSTEM NCA WIRE ORG/BRN WIRE ORG/GRN WIRE RADIO (OR) RADIO/NAVIGATION DISPLAY UNIT CONTROL MODULE RADIO ANTENNA RADIO ANTENNA 2 REAR WINDOW DEFOGGER RED/VIO WIRE RED/YEL WIRE RIGHT ANTENNA MODULE RIGHT REAR BASS SPEAKER RIGHT REAR TREBLE SPEAKER TELEPHONE MICROPHONE VIO/GRN WIRE VIO/YEL WIRE W/ EMERGENCY CALL MODULE W/ MULTI- MEDIA W/O EMERGENCY CALL MODULE W/O MULTI- MEDIA WHT WIRE WHT/BLK WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE FM FREQUENCY FILTER (POSITIVE WIRE) GRN WIRE GRY WIRE GRY/BLU WIRE GRY/YEL WIRE HATCHBACK LEFT REAR BASS SPEAKER LEFT REAR TREBLE SPEAKER NCA WIRE ORG/ WIRE REAR VIEW CAMERA RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT MID TREBLE SPEAKER, BASS SPEAKER SATELLITE ANTENNA VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/GRN WIRE VIO/YEL WIRE WHT WIRE YEL WIRE

ANTENNA BLK WIRE BLU WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE LEFT ANTENNA MODULE NAVIGATION SYSTEM CONTROL MODULE (HATCHBACK) (UNDER DRIVER SEAT) NCA WIRE ORG/ WIRE ORG/BRN WIRE ORG/GRN WIRE RADIO (OR) RADIO/NAVIGATION DISPLAY UNIT CONTROL MODULE RADIO ANTENNA 2 RED WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT ANTENNA MODULE SATELLITE ANTENNA SATELLITE TUNER ANTENNA VIO/GRN WIRE VIO/YEL WIRE W/ REAR VIEW CAMERA W/O REAR VIEW CAMERA W/O DIGITAL SOUND PACKAGE WHT WIRE YEL WIRE

AMPLIFIER BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FUSE 16 FUSE PANEL B GRN WIRE GRN/BLU WIRE GRN/YEL WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT FRONT MID TREBLE SPEAKER, BASS SPEAKER LEFT FRONT TREBLE SPEAKER ORG/BRN WIRE ORG/GRN WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RIGHT FRONT TREBLE SPEAKER SUBWOOFER TELEPHONE/ NAVIGATION SYSTEM SPEAKER WHT WIRE WHT/RED WIRE YEL WIRE
