Blind spot monitoring circuit for Volkswagen Beetle A5 (2011-2019)
Blind spot monitoring circuit
BLIND SPOT DETECTION CONTROL MODULE
BLIND SPOT DETECTION CONTROL MODULE 2
BLIND SPOT DETECTION WARNING LAMP
BLK WIRE
BLK/GRN WIRE
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER EXTERIOR REAR VIEW MIRROR ASSEMBLY
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR ASSEMBLY
FUSE 1
FUSE PANEL C (LEFT END OF DASH)
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
ORG/BLK WIRE
ORG/BRN WIRE
ORG/VIO WIRE
RED/GRN WIRE
WHT WIRE
YEL WIRE
