Backup lamps circuit for Volkswagen Beetle A5 (2011-2019)
Backup lamps circuit
A/T
BACKUP LAMP
BACKUP LAMP SWITCH (M/T)
BLK/BLU WIRE
BLK/GRN WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
CLUTCH POSITION SENSOR
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (2.0L TURBO) (IN PLENUM CHAMBER)
FUSE 13
FUSE 25
FUSE 54
FUSE PANEL C
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY 2 ENERGIZED
LEFT TAILLAMP ASSEMBLY
M/T
MULTI-FUNCTION TRANSMISSION RANGE SWITCH
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
REAR VIEW CAMERA
RED/YEL WIRE
RELEASE BUTTON IN REAR LID HANDLE
RIGHT TAILLAMP ASSEMBLY
TOP OF TRANSMISSION)
TRANSMISSION CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/BLK WIRE
VIO/WHT WIRE
