Electronic power steering circuit for Volkswagen Beetle A5 (2011-2019)
Electronic power steering circuit
1.8L TURBO, 2.0L TURBO 2.0L TURBO DIESEL
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRO- MECHANICAL POWER STEERING MOTOR
ELECTROMECHANICAL POWER STEERING INDICATOR LAMP
FUSE 14
FUSE 3
FUSE PANEL A
FUSE PANEL C
GRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY 2 ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
ORG/BLK WIRE
ORG/BRN WIRE
POWER STEERING CONTROL MODULE
RED WIRE
STEERING ANGLE/STEERING TORQUE SENSOR
WHT WIRE
YEL WIRE
