Wiring diagrams for Volkswagen Beetle A5 (2011-2019)

Automatic a/c circuit Manual a/c circuit

Anti-lock brakes circuit

Access/start circuit Forced entry circuit

Steering column electronic systems control module circuit Vehicle electrical system control module circuit

Computer data lines circuit

Cooling fan circuit

Cruise control circuit

Defoggers circuit

Electronic power steering circuit

Wiring diagram engine performance 1.8l turbo

Wiring diagram engine performance 2.0l turbo

Wiring diagram engine performance 2.0l turbo diesel

Backup lamps circuit Exterior lamps circuit

Ground distribution circuit

Headlights circuit

Horn circuit

Instrument cluster circuit

Courtesy lamps circuit Instrument illumination circuit

Blind spot monitoring circuit Emergency call circuit Navigation circuit, w/o rns 510 & amplifier Navigation circuit, w/o rns 510 w/ amplifier Navigation circuit, w/ rns 510 & amplifier Navigation circuit, w/ rns 510 w/o amplifier Parking assistant circuit Rear view camera circuit Vehicle positioning system control module circuit

Power distribution circuit

Power door locks circuit

Power mirrors circuit

Power seats circuit

Power top/sunroof circuit, convertible Power top/sunroof circuit, except convertible

Power windows circuit

Multimedia interface circuit Radio circuit, w/o rns 510 & amplifier Radio circuit, w/o rns 510 w/ amplifier Radio circuit, w/ rns 510 & amplifier Radio circuit, w/ rns 510 w/o amplifier

Shift interlock circuit, w/ direct shift Shift interlock circuit, w/o direct shift

1.8l turbo, charging circuit 1.8l turbo, starting circuit

2.0l turbo, charging circuit 2.0l turbo, starting circuit

2.0l turbo diesel, charging circuit 2.0l turbo diesel, starting circuit

Supplemental restraints circuit

A/t circuit Direct shift a/t circuit

Trunk & fuel door release circuit, convertible Trunk & fuel door release circuit, hatchback

Buzzer circuit Tire pressure monitoring circuit

Wiper/washer circuit

ALARM HORN ANTI-THEFT IMMOBILIZER READER COIL BLOCKING DIODE EXTERIOR LIGHTS, ANTI-LOCK BRAKES SYSTEMS FUEL FILLER DOOR LOCK IND LAMP HIGH TONE HORN HORN SIGNAL ACTIVATION HORN SYSTEM IGNITION COIL 1 W/ POWER OUTPUT STAGE IGNITION COIL 2 W/ POWER OUTPUT STAGE IGNITION COIL 3 W/ POWER OUTPUT STAGE IGNITION COIL 4 W/ POWER OUTPUT STAGE LEFT WASHER NOZZLE HEATER LOW TONE HORN REAR LID LOCK RIGHT WASHER NOZZLE HEATER TELEPHONE TRANSCEIVER W/ LOCK & START SYSTEM KEYLESS ACCESS W/O LOCK & START SYSTEM KEYLESS ACCESS

CHARGE PRESSURE ACTUATOR CONVERTIBLE TOP LOCKING MOTOR DRIVER DOOR CENTRAL LOCKING SYSTEM MOTOR DRIVER WINDSHIELD WIPER MOTOR EGR VALVE 1, EGR MOTOR, EGR POTENTIOMETER ELECTRO- MECHANICAL POWER STEERING MOTOR ENGINE CONTROLS SYSTEM ENGINE COOLANT LEVEL/TEMPERATURE IND LAMP ENGINE COOLANT TEMPERATURE GAUGE ENGINE SOUND GENERATOR ACTUATOR 1 FRONT PASSENGER DOOR CENTRAL LOCKING SYSTEM MOTOR FUEL FILLER DOOR UNLOCK MOTOR HOT W/ MOTRONIC ENGINE OPENING MOTOR REAR LID OPENING MOTOR RECIRCULATION DOOR MOTOR SECONDARY AIR INJECTION PUMP MOTOR SUNROOF MOTOR

ANTENNA ASSEMBLY DRIVER ACCESS/ START SYSTEM ANTENNA FRONT PASSENGER ACCESS/ START SYSTEM ANTENNA GPS ANTENNA GSM ANTENNA KEYLESS ACCESS AUTHORIZATION ANTENNA READER LEFT ANTENNA MODULE LEFT REAR WINDOW ANTENNA IMPEDANCE CONVERTER LUGGAGE COMPARTMENT ACCESS/START SYSTEM ANTENNA RADIO ANTENNA RADIO ANTENNA 2 REAR BUMPER ACCESS/START AUTHORIZATION ANTENNA RIGHT ANTENNA MODULE RIGHT REAR WINDOW ANTENNA IMPEDANCE CONVERTER ROOF ANTENNA SATELLITE ANTENNA SATELLITE TUNER ANTENNA TELEPHONE ANTENNA VEHICLE INTERIOR ACCESS/ START SYSTEM ANTENNA 1 VEHICLE INTERIOR ACCESS/ START SYSTEM ANTENNA 2

A/C COMPRESSOR REGULATOR VALVE CRUISE CONTROL SWITCH, CRUISE CONTROL SET-BUTTON CRUISE CONTROL SWITCH, SET BUTTON DRIVER INTERIOR LOCKING BUTTON DRIVER'S FRONT WINDOW REGULATOR SWITCH EMERGENCY CALL BUTTON EMERGENCY FLASHER BUTTON EVAP CANISTER PURGE REGULATOR VALVE 1 FRONT PASSENGER DOOR WINDOW REGULATOR SWITCH FRONT PASSENGER INTERIOR LOCKING BUTTON FUEL PRESSURE REGULATOR VALVE GENERATOR W/ VOLTAGE REGULATOR LEFT FRONT WINDOW REGULATOR SWITCH LEFT REAR WINDOW REGULATOR MOTOR PARKING AID BUTTON PASSENGER DOOR WINDOW REGULATOR SWITCH, PUSH BUTTON ILLUMINATION BULB PUSH BUTTON ILLUMINATION BULB REAR LID HANDLE RELEASE BUTTON REAR WINDOW DEFOGGER BUTTON RELEASE BUTTON IN REAR LID HANDLE RIGHT REAR WINDOW REGULATOR MOTOR START SYSTEM BUTTON SUNROOF TILT BUTTON 1, SUNROOF ADJUSTMENT REGULATOR TIPTRONIC DOWNSHIFT BUTTON TIPTRONIC DOWNSHIFT BUTTON ON STEERING WHEEL TIPTRONIC UPSHIFT BUTTON TIPTRONIC UPSHIFT BUTTON ON STEERING WHEEL TIRE PRESSURE MONITORING DISPLAY BUTTON WASTEGATE BYPASS REGULATOR VALVE WINDOW REGULATOR MOTOR WINDSHIELD WIPER INTERMITTENT REGULATOR

HATCHBACK CONVERTIBLE W/ REAR VIEW CAMERA W/O REAR VIEW CAMERA REAR VIEW CAMERA W/ REAR VIEW CAMERA W/ REAR VIEW CAMERA W/O REAR VIEW CAMERA W/O REAR VIEW CAMERA

AUDIO SOURCE CONNECTOR SHIELD DATA LINK CONNECTOR DIAGNOSTIC CONNECTOR

A/C CONTROL MODULE ABS CONTROL MODULE ACCESS/START AUTHORIZATION CONTROL MODULE AIR BAG CONTROL MODULE ANTI-THEFT IMMOBILIZER CONTROL MODULE AUTOMATIC GLOW TIME CONTROL MODULE BLIND SPOT DETECTION CONTROL MODULE BLIND SPOT DETECTION CONTROL MODULE 2 CELL PHONE OPERATING ELECTRONIC, CONTROL MODULE CELL PHONE OPERATING ELECTRONICS CONTROL MODULE CLIMATRONIC CONTROL MODULE CONTROL MODULE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED CONVERTIBLE TOP CONTROL MODULE CONVERTIBLE TOP CONTROL MODULE 2 COOLANT FAN CONTROL MODULE DRIVER DOOR CONTROL MODULE ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE EMERGENCY CALL CONTROL MODULE, COMMUNICATION UNIT EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE ENGINE CONTROL MODULE ENGINE SOUND GENERATOR CONTROL MODULE FRESH AIR BLOWER CONTROL MODULE FRONT PASSENGER DOOR CONTROL MODULE FRONT SEAT HEATING CONTROL MODULE FUEL PUMP CONTROL MODULE HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED INFORMATION ELECTRONIC CONTROL MODULE 1 INFORMATION ELECTRONICS CONTROL MODULE INFORMATION ELECTRONICS CONTROL MODULE 1 INSTRUMENT CLUSTER CONTROL MODULE INSTRUMENT CLUSTER CONTROL MODULE INSTRUMENT CLUSTER MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY MULTI-FUNCTION STEERING WHEEL CONTROL MODULE MULTIMEDIA SYSTEM CONTROL MODULE MULTIMEDIA SYSTEM CONTROL MODULE SHIELD NAVIGATION SYSTEM CONTROL MODULE PARKING AID CONTROL MODULE PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE POWER STEERING CONTROL MODULE POWER SUNROOF CONTROL MODULE RADIATOR FAN CONTROL MODULE RADIO/ NAVIGATION DISPLAY UNIT CONTROL MODULE REDUCING AGENT HEATER CONTROL MODULE STEERING COLUMN ELECTRONICS CONTROL MODULE THROTTLE VALVE CONTROL MODULE TRANSMISSION CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VEHICLE POSITIONING SYSTEM CONTROL MODULE W/ NAVIGATION SYSTEM CONTROL MODULE W/O NAVIGATION SYSTEM CONTROL MODULE WIPER MOTOR CONTROL MODULE

DRIVER CENTRAL LOCKING LOCK UNIT DRIVER DOOR CENTRAL LOCKING LOCK UNIT EMERGENCY CALL MODULE, COMMUNICATION UNIT EXHAUST DOOR CONTROL UNIT FRONT PASSENGER CENTRAL LOCKING LOCK UNIT FRONT PASSENGER DOOR CENTRAL LOCKING LOCK UNIT MICROPHONE UNIT REAR LID LOCK UNIT REAR LID LOCK UNIT/ LUGGAGE COMPARTMENT LAMP SWITCH REDUCING AGENT METERING SYSTEM DELIVERY UNIT

FRESH AIR BLOWER SERIES RESISTOR W/ FUSE FUSE 1 FUSE 2 FUSE 3 FUSE 4 FUSE 5 FUSE 6 FUSE 7 FUSE 8 FUSE 9 FUSE 10 FUSE 13 FUSE 14 FUSE 15 FUSE 16 FUSE 17 FUSE 18 FUSE 19 FUSE 20 FUSE 21 FUSE 22 FUSE 23 FUSE 24 FUSE 25 FUSE 26 FUSE 27 FUSE 28 FUSE 29 FUSE 30 FUSE 31 FUSE 32 FUSE 33 FUSE 34 FUSE 35 FUSE 36 FUSE 37 FUSE 38 FUSE 39 FUSE 40 FUSE 41 FUSE 42 FUSE 43 FUSE 44 FUSE 45 FUSE 46 FUSE 47 FUSE 48 FUSE 49 FUSE 50 FUSE 51 FUSE 52 FUSE 53 FUSE 54 FUSE 55 FUSE 56 FUSE 58 FUSE PANEL A FUSE PANEL B FUSE PANEL C

AUXILIARY HEATER HEATING ELEMENT DRIVER BACKREST HEATING ELEMENT FRONT PASSENGER BACKREST HEATING ELEMENT POSITIVE CRANK CASE VENTILATION HEATING ELEMENT POSITIVE CRANKCASE VENTILATION HEATING ELEMENT REDUCING AGENT LINE HEATER W/ AUXILIARY HEATER

A/C SYSTEM INDICATOR LAMP ABS INDICATOR LAMP AIR BAG INDICATOR LAMP ANTI-THEFT IMMOBILIZER SYSTEM INDICATOR LAMP ASR/ESP INDICATOR LAMP BRAKE PAD WEAR INDICATOR LAMP BRAKE SYSTEM INDICATOR LAMP CENTRAL LOCKING SAFE INDICATOR LAMP CRUISE CONTROL INDICATOR LAMP DAYTIME RUNNING LAMP INDICATOR LAMP DOOR AJAR INDICATOR LAMP ELECTRO- MECHANICAL POWER STEERING INDICATOR LAMP ELECTROMECHANICAL POWER STEERING INDICATOR LAMP ELECTRONIC POWER CONTROL MALFUNCTION INDICATOR LAMP EMERGENCY FLASHER INDICATOR LAMP EMERGENCY FLASHER SWITCH, INDICATOR LAMP ENGINE COOLANT LEVEL/ TEMPERATURE INDICATOR LAMP ENGINE COOLANT LEVEL/TEMPERATURE INDICATOR LAMP ENGINE ELECTRONICS INDICATOR LAMP FRONT PASSENGER AIR BAG DISABLED INDICATOR LAMP FUEL FILLER DOOR LOCK INDICATOR LAMP GENERATOR INDICATOR LAMP GLOW PLUG INDICATOR LAMP HIGH BEAM INDICATOR LAMP HOOD OPEN INDICATOR LAMP LAMP FAILURE INDICATOR LAMP LEFT TURN SIGNAL INDICATOR LAMP LOW FUEL LEVEL INDICATOR LAMP MALFUNCTION INDICATOR LAMP MULTI-FUNCTION INDICATOR MULTI-FUNCTION INDICATOR MEMORY SWITCH MULTI-FUNCTION INDICATOR SELECTION SWITCH MULTI-FUNCTION INDICATOR SELECTION/ MEMORY SWITCH OIL LEVEL INDICATOR LAMP OIL PRESSURE INDICATOR LAMP PARKING BRAKE INDICATOR LAMP SWITCH REAR WINDOW DEFOGGER INDICATOR LAMP RIGHT TURN SIGNAL INDICATOR LAMP SEAT BELT INDICATOR LAMP SHIFT LOCK INDICATOR LAMP TIRE PRESSURE MONITORING DISPLAY INDICATOR TIRE PRESSURE MONITORING DISPLAY INDICATOR LAMP WINDSHIELD WASHER FLUID LEVEL INDICATOR LAMP

ANTI-THEFT IMMOBILIZER IND LAMP BACKUP LAMP BLIND SPOT DETECTION WARNING LAMP BLIND SPOT DETECTION WARNING LAMP IN LEFT EXTERIOR MIRROR BLIND SPOT DETECTION WARNING LAMP IN RIGHT EXTERIOR MIRROR DAYTIME RUNNING LAMP IND LAMP DOOR AJAR IND LAMP DRIVER VANITY MIRROR LAMP ELECTRONIC POWER CONTROL MALFUNCTION IND LAMP EXTERIOR LIGHTS, TRUNK, TAILGATE, FUEL DOORS SYSTEMS FRONT INTERIOR LAMP FRONT PASSENGER VANITY MIRROR LAMP HEADLIGHTS, INTERIOR LIGHTS SYSTEMS HIGH-MOUNTED BRAKE LAMP HIGH-MOUNTED BRAKE LAMP BULB HOOD-OPEN IND LAMP LEFT BACKUP LAMP LEFT BRAKE LAMP LEFT FRONT DOOR AMBIENT LIGHTING BULB 1 LEFT FRONT DOOR AMBIENT LIGHTING BULB 2 LEFT FRONT FOG LAMP LEFT FRONT FOG LAMP BULB LEFT FRONT SIDE MARKER LAMP LEFT FRONT SIDE MARKER LAMP BULB LEFT FRONT TURN SIGNAL BULB LEFT FRONT TURN SIGNAL LAMP LEFT LICENSE PLATE LAMP LEFT REAR FOG LAMP LEFT REAR FOG LAMP BULB LEFT REAR TURN SIGNAL LAMP LEFT TAIL LAMP LEFT TAIL LAMP ASSEMBLY LOW FUEL LEVEL IND LAMP LUGGAGE COMPARTMENT LAMP MALFUNCTION IND LAMP OIL PRESSURE IND LAMP POSITION LAMP REAR FOG LAMP IND LAMP REAR WINDOW DEFOGGER IND LAMP RIGHT BACKUP LAMP RIGHT BRAKE LAMP RIGHT FRONT DOOR AMBIENT LIGHTING BULB 1 RIGHT FRONT DOOR AMBIENT LIGHTING BULB 2 RIGHT FRONT FOG LAMP RIGHT FRONT FOG LAMP BULB RIGHT FRONT SIDE MARKER LAMP RIGHT FRONT SIDE MARKER LAMP BULB RIGHT FRONT TURN SIGNAL BULB RIGHT FRONT TURN SIGNAL LAMP RIGHT LICENSE PLATE LAMP RIGHT REAR TURN SIGNAL LAMP RIGHT TAIL LAMP SELECTOR LEVER SCALE ILLUMINATION BULB TRUNK, TAILGATE, FUEL DOORS, INTERIOR LIGHTS SYSTEMS TURN SIGNAL BULB WINDSHIELD WASHER FLUID LEVEL IND LAMP

ABS HYDRAULIC PUMP AFTER-RUN COOLANT PUMP CHANGE AIR COOLING PUMP CHARGE AIR COOLANT PUMP CHARGE AIR COOLING PUMP HEATER SUPPORT PUMP LEAK DETECTION PUMP REDUCING AGENT PUMP REDUCING AGENT RETURN FLOW PUMP WINDSHIELD WASHER PUMP

A/C CLUTCH RELAY ALARM HORN RELAY ENGINE COMPONENT POWER SUPPLY RELAY FUEL PUMP RELAY HEADLAMP DIMMER/ FLASHER RELAY HIGH HEAT OUTPUT RELAY HOT W/ TERMINAL 15 POWER SUPPLY RELAY 2 ENERGIZED HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED HOT W/ TERMINAL 30 POWER SUPPLY RELAY HOT W/ TERMINAL 30 POWER SUPPLY RELAY ENERGIZED HOT W/ TERMINAL 50 POWER SUPPLY RELAY ENERGIZED HOT W/ TERMINAL 75 POWER SUPPLY RELAY 1 ENERGIZED LOW HEAT OUTPUT RELAY POWER TRAIN CAN BUS CUT-OFF RELAY POWERTRAIN CAN BUS CUTOFF RELAY REDUCING AGENT METERING SYSTEM RELAY RELAY & FUSE CARRIER 1 RELAY & FUSE CARRIER 2 SECONDARY AIR INJECTION PUMP RELAY STARTER RELAY 1 STARTER RELAY 2 SUPPLY RELAY ENERGIZED TERMINAL 15 POWER SUPPLY RELAY TERMINAL 15 POWER SUPPLY RELAY 2 TERMINAL 30 POWER SUPPLY RELAY TERMINAL 50 POWER SUPPLY RELAY TERMINAL 75 POWER SUPPLY RELAY 1

ACCELERATOR PEDAL POSITION SENSOR ACCELERATOR PEDAL POSITION SENSOR 1, 2 ACCELERATOR PEDAL POSITION SENSOR 2 AIR QUALITY SENSOR BRAKE PRESSURE SENSOR 1 CAMSHAFT POSITION SENSOR CENTRAL AIR DOOR MOTOR, POSITION SENSOR CHARGE AIR PRESSURE ACTUATOR POSITION SENSOR CHARGE AIR PRESSURE SENSOR CHARGE AIR TEMPERATURE SENSOR AFTER CHARGE AIR COOLER CLUTCH OIL TEMPERATURE SENSOR/ TRANSMISSION INPUT SPEED SENSOR CLUTCH POSITION SENSOR COMBUSTION CHAMBER PRESSURE SENSOR CYLINDER 1 COMBUSTION CHAMBER PRESSURE SENSOR CYLINDER 2 COMBUSTION CHAMBER PRESSURE SENSOR CYLINDER 3 COMBUSTION CHAMBER PRESSURE SENSOR CYLINDER 4 DEFROSTER DOOR MOTOR, POSITION SENSOR DIFFERENTIAL PRESSURE SENSOR DRIVE SHAFT SPEED SENSOR 1 DRIVE SHAFT SPEED SENSOR 2 DRIVER EXTERIOR DOOR HANDLE TOUCH SENSOR DRIVER FRONT AIR BAG CRASH SENSOR DRIVER HEATED SEAT TEMPERATURE SENSOR/ HEATING ELEMENT DRIVER HEATED SEAT TEMPERATURE SENSOR/HEATING ELEMENT DRIVER SIDE AIR BAG CRASH SENSOR DRIVER THORAX AIR BAG CRASH SENSOR DRIVER'S SEAT POSITION SENSOR EGR VALVE 2, EGR MOTOR 2, EXHAUST GAS RECIRCULATION POSITION SENSOR 2 ENGINE COOLANT LEVEL SENSOR ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET ENGINE SPEED SENSOR EPC THROTTLE DRIVE ANGLE SENSOR 1, 2 ESP SENSOR UNIT EVAPORATOR TEMPERATURE SENSOR EXHAUST GAS RECIRCULATION TEMPERATURE SENSOR 2 EXHAUST GAS TEMPERATURE SENSOR 1 EXHAUST GAS TEMPERATURE SENSOR 2 EXHAUST GAS TEMPERATURE SENSOR 3 EXHAUST GAS TEMPERATURE SENSOR 4 EXHAUST PRESSURE SENSOR 1 FOOTWELL VENT TEMPERATURE SENSOR FRESH AIR/RECIRCULATING AIR/BACK PRESSURE DOOR MOTOR, POSITION SENSOR FRONT PASSENGER EXTERIOR DOOR HANDLE TOUCH SENSOR FRONT PASSENGER HEATED SEAT TEMPERATURE SENSOR/ HEATING ELEMENT FRONT PASSENGER HEATED SEAT TEMPERATURE SENSOR/HEATING ELEMENT FRONT PASSENGER SEAT POSITION SENSOR FRONT PASSENGER SIDE AIR BAG CRASH SENSOR FRONT PASSENGER THORAX AIRBAG CRASH SENSOR FUEL LEVEL SENSOR, TRANSFER FUEL PUMP FUEL LEVEL SENSOR/TRANSFER FUEL PUMP FUEL PRESSURE SENSOR FUEL TEMPERATURE SENSOR HEATED OXYGEN SENSOR HEATER FOR OXYGEN SENSOR 1 AFTER CATALYTIC CONVERTER HIGH PRESSURE SENSOR INTAKE AIR TEMPERATURE SENSOR INTAKE MANIFOLD RUNNER POSITION SENSOR KNOCK SENSOR 1 LEFT FOOTWELL VENT TEMPERATURE SENSOR LEFT FRONT ABS WHEEL SPEED SENSOR LEFT FRONT BRAKE PAD WEAR SENSOR LEFT FRONT INNER PARKING AID SENSOR LEFT FRONT PARKING AID SENSOR LEFT REAR ABS WHEEL SPEED SENSOR LEFT REAR INNER PARKING AID SENSOR LEFT REAR PARKING AID SENSOR LEFT TEMPERATURE CONTROL DOOR MOTOR, POSITION SENSOR LEFT VENT TEMPERATURE SENSOR LOW FUEL PRESSURE SENSOR MASS AIR FLOW SENSOR MASS AIRFLOW SENSOR NOX SENSOR NOX SENSOR CONTROL MODULE OIL LEVEL THERMAL SENSOR OUTSIDE AIR TEMPERATURE SENSOR OXYGEN SENSOR 1 OXYGEN SENSOR 1 AFTER CATALYTIC CONVERTER OXYGEN SENSOR AFTER THREE WAY CATALYTIC CONVERTER OXYGEN SENSOR HEATER PASSENGER OCCUPANT DETECTION SYSTEM PRESSURE SENSOR PASSENGER SIDE FRONT AIR BAG CRASH SENSOR RAIN/LIGHT RECOGNITION SENSOR RECIRCULATION DOOR MOTOR, POSITION SENSOR REDUCING AGENT QUALITY SENSOR REDUCING AGENT RESERVOIR SENSOR REDUCING AGENT TEMPERATURE SENSOR RIGHT FOOTWELL VENT TEMPERATURE SENSOR RIGHT FRONT ABS WHEEL SPEED SENSOR RIGHT FRONT INNER PARKING AID SENSOR RIGHT FRONT PARKING AID SENSOR RIGHT REAR ABS WHEEL SPEED SENSOR RIGHT REAR INNER PARKING AID SENSOR RIGHT REAR PARKING AID SENSOR RIGHT TEMPERATURE CONTROL DOOR MOTOR, POSITION SENSOR RIGHT VENT TEMPERATURE SENSOR SECONDARY AIR INJECTION SENSOR 1/ SOLENOID VALVE SECONDARY AIR INJECTION SENSOR 2 SECONDARY AIR INJECTION SOLENOID VALVE/SECONDARY AIR INJECTION SENSOR 1 SELECTOR LEVER SENSOR CONTROL MODULE SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE SENSOR 1 SENSOR 2 STEERING ANGLE SENSOR STEERING ANGLE, TORQUE SENSOR STEERING ANGLE/STEERING TORQUE SENSOR SUNLIGHT PHOTO SENSOR THROTTLE POSITION SENSOR TO SELECTOR LEVER SENSOR SYSTEM TRANSMISSION FLUID TEMPERATURE SENSOR TRANSMISSION INPUT SPEED SENSOR TRANSMISSION OUTPUT SPEED SENSOR TRANSMISSION OUTPUT SPEED SENSOR 2 TRANSVERSE ACCELERATION SENSOR, ROTATION RATE SENSOR WINDSHIELD WASHER FLUID LEVEL SENSOR

LEFT FRONT BASS SPEAKER LEFT FRONT BASS SPEAKER, MID- TREBLE SPEAKER LEFT FRONT MID TREBLE SPEAKER, BASS SPEAKER LEFT FRONT TREBLE SPEAKER LEFT REAR BASS SPEAKER LEFT REAR TREBLE SPEAKER RIGHT FRONT BASS SPEAKER RIGHT FRONT BASS SPEAKER, MID-TREBLE SPEAKER RIGHT FRONT MID TREBLE SPEAKER, BASS SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT REAR BASS SPEAKER RIGHT REAR TREBLE SPEAKER TELEPHONE/ NAVIGATION SYSTEM SPEAKER

A/C SWITCH BACKUP LAMP SWITCH BACKUP SWITCH BRAKE FLUID LEVEL WARNING SWITCH BRAKE LAMP SWITCH BRAKE LAMP SWITCH, BRAKE PEDAL SWITCH BRAKE LAMP SWITCH/BRAKE PEDAL SWITCH BRAKE LAMP/ BRAKE PEDAL SWITCH BRAKE PEDAL SWITCH, BRAKE LAMP SWITCH BRAKE PEDAL SWITCH/BRAKE LAMP SWITCH CONVERTIBLE TOP LATCH OPEN & CLOSE SWITCH CONVERTIBLE TOP LEFT LOCK SWITCH CONVERTIBLE TOP RIGHT LOCK SWITCH DRIVER DOOR CONTACT SWITCH DRIVER INTERIOR LOCKING SWITCH DRIVER SEAT BELT SWITCH DRIVER VANITY MIRROR LAMP CONTACT SWITCH DRIVER'S FRONT POWER WINDOW SWITCH DRIVER'S SEAT BELT SWITCH DRIVER'S SIDE INTERIOR LOCK SWITCH DRIVING DYNAMIC REGULATION HIGH PRESSURE SWITCH VALVE 2 DRIVING DYNAMICS REGULATION SWITCH VALVE 1 DRIVING DYNAMICS REGULATION SWITCH VALVE 2 LEFT FRONT ABS INLET VALVE ENGINE HOOD CONTACT SWITCH EXTERIOR REAR VIEW MIRROR SWITCH FRESH AIR BLOWER SWITCH FRESH AIR/ RECIRCULATION DOOR SWITCH FRONT PASSENGER DOOR CONTACT SWITCH FRONT PASSENGER INTERIOR LOCK SWITCH FRONT PASSENGER SEAT BELT SWITCH FRONT PASSENGER VANITY MIRROR LAMP CONTACT SWITCH HEADLAMP DIMMER/ FLASHER SWITCH HEADLAMP DIMMER/FLASHER, TURN SIGNAL SWITCH HEADLAMP SWITCH ILLUMINATION BULB IGNITION SWITCH KEY LOCK SOLENOID IGNITION SWITCH KEYLOCK SOLENOID IGNITION/STARTER SWITCH INSTRUMENT PANEL, SWITCH ILLUMINATION DIMMER SWITCH LEFT CONVERTIBLE TOP CLOSED POSITION SWITCH LEFT CONVERTIBLE TOP COMPARTMENT COVER SWITCH LIGHT SWITCH LUGGAGE COMPART- MENT LAMP SWITCH LUGGAGE COMPARTMENT LAMP SWITCH MIRROR ADJUSTING SWITCH MIRROR ADJUSTMENT SWITCH ILLUMINATION MIRROR ADJUSTMENT SWITCH ILLUMINATION BULB MIRROR HEATING SWITCH MIRROR SELECTOR SWITCH MULTI-FUNCTION TRANSMISSION RANGE SWITCH OIL PRESSURE SWITCH PASSENGER SIDE INTERIOR LOCK SWITCH POWER TOP OPERATION SWITCH REAR FOG LAMP SWITCH FOG LAMP SWITCH REDUCED OIL PRESSURE SWITCH RIGHT CONVERTIBLE TOP CLOSED POSITION SWITCH RIGHT CONVERTIBLE TOP COMPARTMENT COVER SWITCH RIGHT FRONT POWER WINDOW SWITCH SELECTOR LEVER PARK POSITION LOCK SWITCH TIPTRONIC SWITCH TOP LEFT LOCK SWITCH TOP RIGHT LOCK SWITCH TURN SIGNAL SWITCH TURN SIGNAL SWITCH/ HEADLAMP DIMMER/ FLASHER SWITCH TURN SIGNAL, HEADLAMP DIMMING/ FLASHER SWITCH WINDSHIELD WIPER INTERMITTENT MODE SWITCH WINDSHIELD WIPER/ WASHER SWITCH WINDSHIELD WIPER/WASHER SWITCH WINDSHIELD, HEADLAMP WASHER PUMP SWITCH

AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 1 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 2 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 3 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 4 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 5 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 7 CAMSHAFT ADJUSTMENT VALVE 1 CYLINDER HEAD CONTROL VALVE CYLINDER HEAD COOLANT VALVE DRIVER ROLLOVER PROTECTION SOLENOID FRONT PASSENGER ROLLOVER PROTECTION SOLENOID FUEL METERING VALVE INTAKE MANIFOLD RUNNER CONTROL VALVE LEFT FRONT ABS OUTLET VALVE LEFT REAR ABS INLET VALVE LEFT REAR ABS OUTLET VALVE OIL PRESSURE REGULATION VALVE RIGHT FRONT ABS INLET VALVE RIGHT FRONT ABS OUTLET VALVE RIGHT REAR ABS INLET VALVE SHIFT LOCK SOLENOID SOLENOID VALVE 1 SOLENOID VALVE 2 SOLENOID VALVES TURBOCHARGER RECIRCULATION VALVE

(OR RED/ WIRE BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/VIO WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RUN WIRE VIO WIRE VIO/BLK WIRE VIO/BLU WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE YEL/VIO WIRE

1.8L TURBO, 2.0L TURBO 1.8L TURBO, 2.0L TURBO 2.0L TURBO DIESEL 1.8L TURBO, 2.0L TURBO CPPA 1.8L TURBO, 2.0L TURBO CPPL 2.0L TURBO 2.0L TURBO CPLA 2.0L TURBO DIESEL 2.0L TURBO DIESEL 2.0L TURBO, 1.8L TURBO 2.0L TURBO, 1.8L TURBO 2.0L TURBO DIESEL 2.0L TURBO, 1.8L TURBO CONVERTIBLE HATCHBACK (OR ACCELERATOR PEDAL MODULE ADAPTER CABLE ADJUSTMENT MOTORS AIR BAG SPIRAL SPRING/RETURN SPRING W/ SLIP RING AIR CONDITIONING SYSTEM ANTI-THEFT SYSTEM AUTOMATIC A/C AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR AUTOMATIC TRANSMISSION HYDRAULIC PRESSURE SENSORS AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVES AUXILIARY INSTRUMENTS AUXILIARY VIDEO/ AUDIO CONNECTION MODULE BACKUP LAMPS CIRCUIT CELLULAR TELEPHONE PREPARATION CONTROL HEAD CHARGE AIR PRESSURE GAUGE CHARGING CIRCUIT CHARGING SYSTEM CIGARETTE LIGHTER COMPUTER DATA COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEMS COMPUTER LINES DATA SYSTEM CONVERTER BOX CONVERTIBLE HATCHBACK W/ TIPTRONIC W/O TIPTRONIC CONVERTIBLE HATCHBACK W/O DIRECT SHIFT COOLING FANS COOLING FANS SYSTEM COURTESY LAMPS CIRCUIT CRUISE CONTROL SYSTEM DATA BUS ON BOARD DIAGNOSTIC INTERFACE DATA LINES DEFOGGER SYSTEM DOOR LOCKS SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR LOCKS, ANTI-THEFT, TRUNK, TAILGATE, FUEL DOORS SYSTEMS DRIVER EXTERIOR DOOR HANDLE DRIVER EXTERIOR REAR VIEW MIRROR ASSEMBLY DRIVER HEATED SEAT ADJUSTER DRIVER SEAT BELT TENSIONER IGNITER 1, DRIVER BELT FORCE LIMITER DRIVER THORAX AIR BAG IGNITER DRIVER WINDOW LOWERING MICROSWITCH DRIVER'S AIR BAG IGNITER DRIVER'S HEATED SEAT ADJUSTER DSG TRANSMISSION MECHATRONIC EPC THROTTLE EXCEPT 2.0L TURBO DIESEL EXTERNAL AUDIO SOURCE CONNECTION FRESH AIR BLOWER FRESH AIR, RECIRCULATION MODE IND LIGHT FRONT PARKING AID WARNING BUZZER FRONT PASSENGER AIR BAG IGNITER 1, 2 FRONT PASSENGER EXTERIOR DOOR HANDLE FRONT PASSENGER EXTERIOR REAR VIEW MIRROR ASSEMBLY FRONT PASSENGER HEATED SEAT ADJUSTER FRONT PASSENGER THORAX AIR BAG IGNITER FRONT PASSENGER WINDOW LOWERING MICROSWITCH FRONT PASSENGER'S EXTERIOR REAR VIEW MIRROR ASSEMBLY FRONT PASSENGER'S HEATED SEAT ADJUSTER FUEL GAUGE GEAR POSITION DISTANCE SENSORS HATCHBACK CONVERTIBLE W/O START/STOP SYSTEM W/ START/STOP SYSTEM HEADLIGHTS SYSTEM HIGH BEAM HORNS SYSTEM HOT AT ALL TIMES HOT W/ TERMINAL 30 IGNITIER 1 IGNITIER 2 IN PLENUM CHAMBER) INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM INSTRUMENT ILLUMINATION CIRCUIT LEFT FRONT HEADLAMP LEFT MULTI-FUNCTION BUTTONS LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL LEFT TAILLAMP ASSEMBLY LINES SYSTEM LOW BEAM MANUAL A/C MANUAL A/C AUTOMATIC A/C CONVERTIBLE HATCHBACK MANUAL A/C AUTOMATIC A/C HATCHBACK CONVERTIBLE 2.0L TURBO DIESEL MIRRORS SYSTEM MULTIMEDIA INTERFACE CIRCUIT NAVIGATION SYSTEM NOT USED NOT USED POWER DISTRIBUTION SYSTEM R-O-L RADIATOR FAN RADIATOR OUTLET REAR PARKING AID WARNING BUZZER REAR WINDOW DEFOGGER REDUCING AGENT INJECTOR RIGHT FRONT HEADLAMP RIGHT MULTI-FUNCTION BUTTONS RIGHT MULTI-FUNCTION BUTTONS ON STEERING WHEEL RIGHT RADIATOR FAN RIGHT TAILLAMP ASSEMBLY SEATS SYSTEM SECONDARY AIR SYSTEM SELECTOR LEVER SPEEDO- METER STARTING CIRCUIT STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM STARTING/CHARGING, ANTI-THEFT SYSTEMS STEERING COLUMN ELECTRONIC SYSTEM CONTROL CIRCUIT SUPPLEMENTAL RESTRAINTS SYSTEM TELEPHONE MICROPHONE TEMPERATURE SELECTOR KNOB POTENTIOMETER TO SPARK PLUG TO VEHICLE ELECTRICAL SYSTEM TOP OF TRANSMISSION) TRANSMISSION ASSEMBLY TRANSMISSION RANGE DISPLAY TRANSMISSIONS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM TURN SIGNAL USB CONNECTION BASE PLATE W/ ACCESS/ START AUTHORIZATION W/ CELL PHONE W/ DIGITAL RADIO W/ DIRECT SHIFT W/ DIRECT SHIFT 1.8L TURBO, 20L TURBO 2.0L TURBO DIESEL W/ DUAL CLUTCH TRANSMISSION W/ EMERGENCY CALL MODULE W/ GPS W/ GSM W/ HID W/ HID W/O HID W/ MULTI- MEDIA W/ MULTI-FUNCTION STEERING WHEEL CONTROLS W/ NAVIGATION W/ SATELLITE W/O AUTOMATIC HEADLAMP RANGE CONTROL W/O CELL PHONE W/O DIGITAL SOUND PACKAGE W/O DIRECT SHIFT W/O EMERGENCY CALL MODULE W/O MULTI- MEDIA W/O MULTI-FUNCTION STEERING WHEEL CONTROLS WARNING BUZZER, TONE WIPER/ WASHER SYSTEM WIPER/WASHER SYSTEM
