Volkswagen Beetle A4 facelift (2005-2011) Exterior lamps circuit

BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/WHT/GRN WIRE BLK/YEL WIRE BRAKE LIGHT SWITCH (ABOVE BRAKE PEDAL) BRN WIRE CONTROL MODULE CONVERTIBLE EXCEPT CONVERTIBLE DRIVER EXTERIOR MIRROR TURN SIGNAL LIGHT EMERGENCY FLASHER SWITCH FRONT PASSENGER EXTERIOR MIRROR TURN SIGNAL LIGHT FUSE 239 FUSE 2 FUSE 3 FUSE 23 FUSE 4 FUSE 22 FUSE 13 FUSE PANEL (BEHIND LEFT SIDE OF DASH) GRN WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/YEL WIRE HEAD HEAD OFF OFF PARK PARK HEADLIGHTS SYSTEM (FOG LIGHT RELAY) HIGH MOUNT BRAKE LIGHT HOT AT ALL TIMES HOT IN ON INSTRUMENT CLUSTER LEFT FRONT TURN SIGNAL LIGHT LEFT FRONT SIDE MARKER LIGHT LEFT HEAD LIGHT ASSEMBLY LEFT PARKING LAMP LEFT RIGHT LEFT RIGHT TURN IND TURN IND LICENSE PLATE LIGHTS LIGHT SWITCH LOAD REDUCTION RELAY MOTRONIC ENGINE CONTROL MODULE (BELOW LEFT SIDE OF DASH COVER) OFF PARK RED WIRE RED/BLK WIRE RED/BRN WIRE RED/GRN WIRE RIGHT FRONT SIDE MARKER LIGHT RIGHT FRONT TURN SIGNAL LIGHT RIGHT HEAD LIGHT ASSEMBLY RIGHT PARKING LAMP RIGHT REAR TURN SIGNAL LIGHT LEFT REAR TURN SIGNAL LIGHT SOLID STATE TURN SIGNAL SWITCH WHT WIRE
