Tire pressure monitoring circuit for Volkswagen Atlas I facelift (2020-2023)
Tire pressure monitoring circuit
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 7
FUSE PANEL C
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
LEFT FRONT TIRE PRESSURE MONITORING SENSOR
LEFT REAR TIRE PRESSURE MONITORING SENSOR
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/YEL WIRE
RIGHT FRONT TIRE PRESSURE MONITORING SENSOR
RIGHT REAR TIRE PRESSURE MONITORING SENSOR
TIRE PRESSURE MONITORING CONTROL MODULE
TIRE PRESSURE MONITORING DISPLAY INDICATOR LAMP
YEL WIRE
