Heated seats circuit for Volkswagen Atlas I facelift (2020-2023)

Heated seats circuit (1 of 2)

Atlas Volkswagen I facelift (2020-2023): Heated seats circuit (1 of 2)

Get access

BLK/RED WIRE BRN WIRE BRN/BLK WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FUSE 26 FUSE 33 FUSE 51 FUSE 7 FUSE PANEL C GRN/BLK WIRE GRN/BLU WIRE HEATED DRIVER SEAT INDICATOR LAMP HEATED FRONT PASSENGER SEAT INDICATOR LAMP HEATER, A/C CONTROLS HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT FRONT SEAT COUPLING STATION LEFT REAR BACKREST HEATING ELEMENT LEFT REAR HEATED SEAT TEMPERATURE SENSOR LEFT REAR SEAT COUPLING POINT LEFT REAR SEAT COUPLING STATION LEFT REAR SEAT HEATER LEFT REAR SEAT HEATING BUTTON LEFT REAR SEAT HEATING ELEMENT LEFT SEAT HEATING BUTTON ORG/BRN WIRE ORG/GRN WIRE REAR A/C DISPLAY CONTROL HEAD RED/BLU WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR SEAT HEATING BUTTON RIGHT SEAT HEATING BUTTON VIO/BLU WIRE YEL/BLK WIRE

Heated seats circuit (2 of 2)

Atlas Volkswagen I facelift (2020-2023): Heated seats circuit (2 of 2)

Get access

BLK/RED WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM CROSS SPORT DRIVER BACKREST HEATING ELEMENT DRIVER SEAT HEATING ELEMENT DRIVER SIDE HEATED SEAT (IF EQUIPPED) EXCEPT CROSS SPORT FRONT PASSENGER BACKREST HEATING ELEMENT FRONT PASSENGER SEAT HEATING ELEMENT GRN/BLK WIRE GROUND DISTRIBUTION SYSTEM LEFT FRONT SEAT COUPLING STATION LEFT FRONT SEAT TEMPERATURE SENSOR NCA WIRE ORG/BRN WIRE ORG/GRN WIRE PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT SEAT COUPLING STATION RIGHT FRONT SEAT TEMPERATURE SENSOR RIGHT REAR BACKREST HEATING ELEMENT RIGHT REAR HEATED SEAT TEMPERATURE SENSOR RIGHT REAR SEAT COUPLING POINT RIGHT REAR SEAT COUPLING STATION RIGHT REAR SEAT HEATER RIGHT REAR SEAT HEATING ELEMENT VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/BLK WIRE
