Exterior lamps circuit for Volkswagen Atlas I facelift 2 (2023-2024)

AUTOMATIC LIGHT CONTROL INDICATOR LAMP BLK/GRN WIRE BLK/RED WIRE BRN WIRE CENTER INSTRUMENT PANEL SWITCH MODULE COMPUTER DATA LINES SYSTEM EMERGENCY FLASHER BUTTON EMERGENCY FLASHER INDICATOR LAMP FUSE 44 FUSE PANEL C GRN WIRE GRY/RED WIRE HOT AT ALL TIMES ILLUMINATION CONTROL HEAD LEFT BRAKE LAMP BULB LEFT REAR FOG LAMP BULB LEFT REAR TURN SIGNAL BULB LEFT TAIL LAMP LEFT TAIL LAMP BULB LIGHT SWITCH ORG/BRN WIRE POSITION LAMP BUTTON POSITION LAMP INDICATOR LAMP RAIN/LIGHT RECOGNITION SENSOR REAR FOG LAMP BUTTON REAR FOG LAMP INDICATOR LAMP RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RIGHT BRAKE LAMP BULB RIGHT REAR FOG LAMP BULB RIGHT REAR TURN SIGNAL BULB RIGHT TAIL LAMP RIGHT TAIL LAMP BULB VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/WHT WIRE WHT WIRE WHT/GRN WIRE

BACKUP LAMPS CIRCUIT BLK/WHT WIRE BLU/GRN WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR BRAKE LAMP SWITCH BRN WIRE CENTER TAIL LAMP ENGINE/MOTOR CONTROL MODULE FUSE 31 FUSE PANEL B GRY/RED WIRE HIGH-MOUNTED BRAKE LAMP BULB HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED LEFT BACKUP LAMP BULB LEFT COUPLING POINT ON REAR LID LEFT LICENSE PLATE LAMP LEFT TAIL LAMP BULB 2 REAR FOG LAMP BULB REAR LID COUPLING POINT RED/BLK WIRE RIGHT BACKUP LAMP BULB RIGHT LICENSE PLATE LAMP RIGHT TAIL LAMP BULB 2 TOWING RECOGNITION CONTROL MODULE VIO/WHT WIRE WHT WIRE WHT/GRN WIRE

BLK/BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE DRIVER EXTERIOR REAR VIEW MIRROR DRIVER EXTERIOR REAR VIEW MIRROR TURN SIGNAL BULB FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER EXTERIOR REAR VIEW MIRROR FRONT PASSENGER EXTERIOR REAR VIEW MIRROR TURN SIGNAL BULB FUSE 4 FUSE 45 FUSE 5 FUSE PANEL B FUSE PANEL C GRN WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE LEFT FRONT HEADLAMP LEFT FRONT TURN SIGNAL BULB LEFT STATIONARY CORNERING LAMP MIRRORS SYSTEM ORG/BRN WIRE ORG/GRY WIRE RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE RIGHT FRONT HEADLAMP RIGHT FRONT TURN SIGNAL BULB RIGHT STATIONARY CORNERING LAMP STEERING COLUMN ELECTRONICS CONTROL MODULE TURN SIGNAL SWITCH VIO/BLK WIRE VIO/WHT WIRE WHT WIRE YEL WIRE
