Volkswagen Atlas Cross Sport I (2019-2023) push button illumination lamp Wiring diagram
This page shows the only wiring diagram for the component.push button illumination lamp, which is found in the car Volkswagen Atlas Cross Sport I (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram push button illumination lamp (1 of 1)
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
CENTER CONSOLE SWITCH MODULE 2
CROSS SPORT
CROSS SPORT EXCEPT CROSS SPORT
EXCEPT CROSS SPORT
GRY WIRE
LEFT REAR CENTER PARKING AID SENSOR
LEFT REAR PARALLEL PARKING ASSISTANCE SENSOR
LEFT REAR PARKING AID SENSOR
PARALLEL PARKING ASSISTANCE BUTTON
PARALLEL PARKING ASSISTANCE INDICATOR LAMP
PARKING AID BUTTON
PARKING AID INDICATOR LAMP
PUSH BUTTON ILLUMINATION LAMP
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT COUPLING POINT IN LUGGAGE COMPARTMENT
RIGHT REAR CENTER PARKING AID SENSOR
RIGHT REAR PARALLEL PARKING ASSISTANCE SENSOR
RIGHT REAR PARKING AID SENSOR
VIO/BLU WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
VIO/YEL WIRE
Go to component -> Parking assistant circuit (2 of 2) -> PUSH BUTTON ILLUMINATION LAMP
