Volkswagen Atlas Cross Sport I (2019-2023) front passenger's air bag disabled indicator lamp Wiring diagram
This page shows the only wiring diagram for the component.front passenger's air bag disabled indicator lamp, which is found in the car Volkswagen Atlas Cross Sport I (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's air bag disabled indicator lamp (1 of 1)
AIR BAG CONTROL MODULE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
CENTER INSTRUMENT PANEL SWITCH MODULE
COMPUTER DATA LINES SYSTEM
CROSS SPORT
DRIVER SEAT BELT SWITCH
DRIVER SEAT BELT TENSIONER IGNITER 2
DRIVER SEAT POSITION SENSOR
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
FRONT PASSENGER AIR BAG IGNITER 1
FRONT PASSENGER AIR BAG IGNITER 2
FRONT PASSENGER AIR BAG UNIT
FRONT PASSENGER SEAT BELT SWITCH
FRONT PASSENGER THORAX AIR BAG IGNITER
FRONT PASSENGER'S AIR BAG DISABLED INDICATOR LAMP
FUSE 33
FUSE 34
FUSE PANEL C
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
LEFT FRONT SEAT ADJUSTMENT CONTROL HEAD
LEFT FRONT SEAT COUPLING POINT
LEFT FRONT SEAT COUPLING STATION
RED WIRE
RIGHT FRONT SEAT ADJUSTMENT CONTROL HEAD
RIGHT FRONT SEAT COUPLING POINT
RIGHT FRONT SEAT COUPLING STATION
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> FRONT PASSENGER'S AIR BAG DISABLED INDICATOR LAMP
