Volkswagen Atlas Cross Sport I (2019-2023) except cross port Wiring diagram
This page shows the only wiring diagram for the component.except cross port, which is found in the car Volkswagen Atlas Cross Sport I (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram except cross port (1 of 1)
BLU WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/VIO WIRE
CHILD SAFETY LOCK BUTTON
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER DOOR POWER WINDOW CONTROL HEAD
DRIVER POWER WINDOW BUTTON
DRIVER SIDE REAR POWER WINDOW BUTTON
DRIVER SIDE REAR WINDOW REGULATOR MOTOR
EXCEPT CROSS PORT
FRONT PASSENGER POWER WINDOW BUTTON
FUSE 25
FUSE 39
FUSE PANEL C
GRN WIRE
GRY WIRE
GRY/BRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
LEFT CHILD SAFETY LOCK- ACTIVATED- INDICATOR LAMP
LEFT FRONT DOOR COUPLING POINT
LEFT REAR DOOR COUPLING POINT
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER SIDE REAR POWER WINDOW BUTTON
PUSH BUTTON ILLUMINATION BULB
REAR POWER WINDOW LOCK INDICATOR LAMP
REAR WINDOW REGULATOR SAFETY SWITCH
RED/WHT WIRE
RED/YEL WIRE
RIGHT CHILD SAFETY LOCK- ACTIVATED- INDICATOR LAMP
RIGHT FRONT DOOR COUPLING POINT
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/GRN WIRE
W/ PERIPHERAL CAMERA W/O PERIPHERAL CAMERA
WHT WIRE
WHT/BLU WIRE
Go to component -> Power windows circuit (1 of 2) -> EXCEPT CROSS PORT
