Volkswagen Arteon I facelift (2020-2024) Supplemental restraints circuit

AIR BAG CONTROL MODULE BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER SEAT BELT BUCKLE DRIVER SEAT BELT SWITCH DRIVER SEAT BELT TENSIONER IGNITER 2 DRIVER SEAT POSITION SENSOR FRONT PASSENGER BELT FORCE LIMITER FRONT PASSENGER HEAD CURTAIN AIR BAG IGNITER FRONT PASSENGER KNEE AIR BAG IGNITER FRONT PASSENGER SEAT BELT TENSIONER IGNITER 1 FRONT PASSENGER SEAT BELT TENSIONER IGNITER 2 FRONT PASSENGER THORAX AIR BAG IGNITER FUSE 33 FUSE 48 FUSE PANEL C GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT FRONT SEAT COUPLING STATION PASSENGER SIDE REAR SEAT BELT TENSIONER IGNITER POWER DISTRIBUTION SYSTEM RED WIRE RED/YEL WIRE RIGHT FRONT SEAT BELT RIGHT FRONT SEAT COUPLING STATION WHT WIRE WHT/RED WIRE

AIR BAG IGNITER 1 AIR BAG IGNITER 2 AIR BAG SPIRAL SPRING/RETURN SPRING W/ SLIP RING BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER AIR BAG IGNITER EARLY PRODUCTION FRONT PASSENGER AIR BAG UNIT (RIGHT SIDE OF DASH) FRONT PASSENGER SEAT BELT SWITCH FRONT PASSENGER SEAT POSITION SENSOR GRN WIRE GRN/BLK WIRE GRN/YEL WIRE GRY WIRE LATE PRODUCTION ORG/BRN WIRE RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT SEAT ADJUSTMENT CONTROL HEAD RIGHT FRONT SEAT COUPLING STATION SEAT OCCUPANT DETECTION SYSTEM CONTROL MODULE SEAT OCCUPANT DETECTION SYSTEM PRESSURE SENSOR SEATS SYSTEM STEERING COLUMN ELECTRONICS CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/BLK WIRE W/ HEATED STEERING WHEEL W/O HEATED STEERING WHEEL WHT WIRE YEL WIRE

AIR BAG IND LAMP BLK WIRE BLU WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER SIDE PEDESTRIAN PROTECTION CRASH SENSOR DRIVER SIDE PEDESTRIAN PROTECTION CRASH SENSOR 2 FRONT PASSENGER SIDE PEDESTRIAN PROTECTION CRASH SENSOR FRONT PASSENGER SIDE PEDESTRIAN PROTECTION CRASH SENSOR 2 GRN WIRE GRY WIRE GRY/BLK WIRE INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT ORG/BRN WIRE PEDESTRIAN PROTECTION CENTER CRASH SENSOR PEDESTRIAN PROTECTION TRIGGER 1 PEDESTRIAN PROTECTION TRIGGER 2 PRESSURE HOSE SENSOR FRONT PEDESTRIAN PROTECTION RED WIRE RED/YEL WIRE VIO/BLK WIRE WHT/VIO WIRE YEL WIRE YEL/GRY WIRE

AIR BAG CONTROL MODULE BLK WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER BELT FORCE LIMITER DRIVER HEAD CURTAIN AIR BAG IGNITER DRIVER KNEE AIR BAG IGNITER DRIVER SEAT BELT TENSIONER IGNITER 1 DRIVER SIDE REAR SEAT BELT TENSIONER IGNITER DRIVER SIDE REAR THORAX AIR BAG CRASH SENSOR DRIVER THORAX AIR BAG CRASH SENSOR DRIVER THORAX AIR BAG IGNITER FRONT PASSENGER THORAX AIR BAG CRASH SENSOR GRN WIRE GRY WIRE GRY/BLK WIRE LEFT FRONT DOOR COUPLING POINT LEFT FRONT SEAT BELT LEFT FRONT SEAT COUPLING STATION ORG/BRN WIRE PASSENGER SIDE REAR THORAX AIR BAG CRASH SENSOR RED WIRE RED/YEL WIRE RIGHT FRONT DOOR COUPLING POINT VIO WIRE VIO/BLK WIRE W/ PERIPHERAL CAMERA W/O PERIPHERAL CAMERA WHT WIRE WHT/VIO WIRE YEL WIRE YEL/GRY WIRE
