Car Wiring Diagrams for Charging circuit for Toyota Yaris III facelift 2 (2016-2020)

ALT ALT FUSE ALT-S FUSE BATTERY BLK WIRE BLU WIRE CHARGE IND COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ENGINE ROOM J/B ENGINE ROOM R/B FUSIBLE LINK BLOCK GAUGE FUSE GENERATOR ASSEMBLY GRN WIRE HOT IN ON OR START INSTRUMENT PANEL J/B LED DRIVER MAIN FUSE MET FUSE PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE STARTER ASSEMBLY WHT WIRE YEL WIRE
