Cooling fan circuit for Toyota Yaris III facelift 2 (2016-2020)

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COOLING FAN MOTOR COOLING FAN RESISTOR E.F.I. ENGINE COOLANT TEMPERATURE SENSOR ECU- IG 1 FUSE ENGINE ROOM J/B ENGINE ROOM R/B FAN RELAY 1 FAN RELAY 2 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT PANEL J/B RDI FAN FUSE RED WIRE VIO WIRE WHT WIRE WHT/BLK WIRE
