Toyota Yaris III facelift 2 (2016-2020) horn button wire sub- assembly Wiring diagram
This page shows the only wiring diagram for the component.horn button wire sub- assembly, which is found in the car Toyota Yaris III facelift 2 (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram horn button wire sub- assembly (1 of 1)
BLK WIRE
CRUISE CONTROL SWITCH WIRE
ENGINE ROOM J/B
HORN
HORN BUTTON WIRE SUB- ASSEMBLY
HORN FUSE
HORN RELAY
HORN SWITCH
HOT AT ALL TIMES
INSTRUMENT PANEL J/B
LOW PITCHED HORN ASSEMBLY
LT GRN WIRE
MAIN BODY ECU
SPIRAL W/ SENSOR CABLE SUB-ASSEMBLY
STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
STEERING WHEEL)
W/ CRUISE CONTROL, STEERING PAD SWITCH ASSEMBLY
W/ CRUISE CONTROL, W/O STEERING PAD SWITCH ASSEMBLY
W/O CRUISE CONTROL, STEERING PAD SWITCH ASSEMBLY
Go to component -> Horn circuit -> HORN BUTTON WIRE SUB- ASSEMBLY
