Key reminder & seat belt warning circuit, hatchback for Toyota Yaris III (2010-2014)

13 22 17 23 CANH CANL P-AB PAON 17 13 14 30 KSW CANL CANH TAIL 9 17 10 18 14 13 11 12 LSP+ LSP- LBE+ LBE- AIR BAG SENSOR ASSEMBLY CENTER (CENTER OF DASH) BLK WIRE BLU WIRE BUCKLE SWITCH COMPUTER DATA LINES SYSTEM DRIVER'S SIDE FRONT SEAT INNER BELT (LEFT FRONT SEAT) ECU- IG 1 FUSE FLCY TAIL RELAY FUSE GAUGE FUSE GRN WIRE GRY WIRE HOT IN ON OR ACC HOT IN ON OR START INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) J/B 8 (RIGHT KICK PANEL) LT BLU WIRE LT GRN WIRE MAIN BODY ECU (LEFT SIDE OF DASH) P-AB PAON PASSENGER SEAT BELT WARNING LIGHT PNK WIRE RED WIRE SEAT POSITION AIR BAG SENSOR TELLTALE LIGHT ASSEMBLY UNLOCK WARNING SWITCH (LEFT SIDE OF DASH) W/ BUILT-IN TYPE YAW RATE SENSOR W/ SEPARATE TYPE YAW RATE SENSOR W/ DAY TIME RUNNING LIGHT, THEFT DETERRENT SYSTEM W/O DAY TIME RUNNING LIGHT, THEFT DETERRENT SYSTEM WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE

BLK WIRE BLU WIRE BUZZER CAN I/F COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM CPU CAN CONTROLLER DOME FUSE DOOR IND DRIVER'S SEAT BELT ECU-B 1 FUSE ECU-B 2 FUSE ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) GRN WIRE HEAD HEADLIGHT DIMMER SWITCH ASSEMBLY HOT AT ALL TIMES HOT IN ON OR START IND INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) J/B 7 (LEFT KICK PANEL) LED DRIVER LEFT FRONT DOOR COURTESY LIGHT SWITCH LT BLU WIRE MET FUSE PNK WIRE TAIL OFF WHT WIRE WHT/BLK WIRE
