Courtesy lamps circuit, hatchback for Toyota Yaris III (2010-2014)

BACK DOOR LOCK ASSEMBLY (BASE OF BACK DOOR) BLK WIRE BLU WIRE BRN WIRE COURTESY DOME FUSE DOOR ECU- IG 1 FUSE ECU-B 1 FUSE ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FUSE GRN WIRE HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) J/B 7 (LEFT KICK PANEL) J/B 8 (RIGHT KICK PANEL) LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY LEFT FRONT DOOR W/ MOTOR LOCK ASSEMBLY LEFT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY (5 DOOR) LT BLU WIRE LT GRN WIRE MAIN BODY ECU MAP LIGHT ASSEMBLY OFF PNK WIRE RED WIRE RIGHT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY RIGHT FRONT DOOR W/ MOTOR LOCK ASSEMBLY RIGHT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY (5 DOOR) ROOM LIGHT ASSEMBLY 2 UNLOCK DETECTION UNLOCK WARNING SWITCH ASSEMBLY (LEFT SIDE OF DASH) W/ DRL, THEFT DETERRENT SYSTEM W/O BACK DOOR OPENER W/ BACK DOOR OPENER W/O DRL, THEFT DETERRENT SYSTEM WHT/BLK WIRE YEL WIRE
