Cooling fan circuit, sedan for Toyota Yaris III (2010-2014)

21 22 41 49 FAN 96 97 PNK ETHW THW WIRE BLK WIRE BLU WIRE CAN-H- CAN-L- COMPUTER DATA LINES SYSTEM COOLING FAN MOTOR (CENTER RADIATOR SUPPORT) ECU-IG FUSE ENGINE CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) ENGINE COOLANT TEMPERATURE SENSOR (TOP REAR OF ENGINE) ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FAN RELAY 1 FAN RELAY 2 HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) LT GRN WIRE ORG/ WIRE PNK 1 WIRE RADIATOR FAN RESISTOR (LEFT FRONT OF ENGINE COMPT) RDI FUSE WHT WIRE WHT/BLK WIRE
