Manual a/c circuit, sedan for Toyota Yaris III (2010-2014)

A/C AMPLIFIER (CENTER OF DASH) A/C COMPRESSOR (LEFT FRONT OF ENGINE) A/C PRESSURE SENSOR (LEFT FRONT OF ENGINE) ALL TIMES HOT AT AMBIENT TEMPERATURE SENSOR (BEHIND FRONT GRILLE) B/V A/C LED BLK WIRE BLU WIRE BRN WIRE ENGINE CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) ENGINE COOLANT TEMPERATURE SENSOR ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B 2 (RIGHT SIDE OF ENGINE COMPT) FAN CAN CAN FAN GRN WIRE GRY WIRE HEAT (+) HLS ALT PNK WIRE HTR SUB 2 FUSE HTR SUB 1 FUSE J/B 6 (RIGHT KICK PANEL) LT GRN WIRE MAIN BODY ECU (W/ PTC HEATER) (LEFT SIDE OF DASH) ORG/ WIRE PNK WIRE PTC HEATER (IF EQUIPPED) (CENTER OF DASH) RED WIRE STARTING/ CHARGING SYSTEM TX + TX - SG-2 TAM PRE SOL + IG+ SBLW TE SG-1 GND VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

10 6 7 HI A/C FUSE A/C SW A/C SWITCH A/C THERMISTOR 1 (CENTER OF DASH) BLK WIRE BLOWER RESISTOR (RIGHT SIDE OF DASH) BLOWER SWITCH BLU WIRE BRN WIRE COOLING FAN MOTOR (CENTER RADIATOR SUPPORT) DEFROSTER MODE DETECTION SW ECU-IG FUSE ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FAN RELAY 1 FAN RELAY 2 GAUGE FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES ENGINE ROOM HOT IN ON OR START HTR RELAY INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) LT GRN WIRE MAX HOT SW OFF ORG/ WIRE PNK WIRE R/B (LEFT SIDE OF ENGINE COMPT) HTR FUSE RDI FUSE REAR WINDOW DEFOGGER SWITCH RED WIRE VIO WIRE W/ A/C SWITCH W/ DEFROSTER DETECTION SWITCH, W/ A/C SWITCH W/O A/C SWITCH W/O DEFROSTER DETECTION SWITCH, W/ A/C SWITCH W/O PTC HEATER WHT WIRE WHT/BLK WIRE YEL WIRE
