Toyota Yaris III (2010-2014) light control turn switch switch headlight dimmer switch assembly wiring diagram
This page shows the only wiring diagram for the component.light control turn switch switch headlight dimmer switch assembly, which is found in the car Toyota Yaris III (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
light control turn switch switch headlight dimmer switch assembly wiring diagram (1 of 1)
22 20 19 21 18 PNK WIRE
ALT FUSE
BLK WIRE
BLU WIRE
BRN WIRE
ECU- IG 1 FUSE
FUSE
FUSIBLE LINK BLOCK (LEFT REAR OF ENGINE COMPT)
GRN WIRE
HEAD TAIL DRL OFF AUTO
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR ACC
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
INTERIOR LIGHTS COMPUTER SYSTEM DATA LINES SYSTEM
J/B 7 (LEFT KICK PANEL)
J/B 8 (RIGHT KICK PANEL) J/B 7 (LEFT KICK PANEL)
LEFT
LEFT HEADLIGHT UNIT
LIGHT CONTROL TURN SWITCH SWITCH HEADLIGHT DIMMER SWITCH ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
PARKING
PNK 7 8 WIRE
PNK WIRE
RED WIRE
RIGHT
RIGHT HEADLIGHT UNIT
SHIFT LOCK CONTROL ECU (UNDER CENTER FLOOR CONSOLE)
SIDE MARKER
TAIL
TAIL 2 FUSE
TAIL RELAY
TELLTALE TB LIGHT HAZARD ASSEMBLY SWITCH
TURN
VIO WIRE
W/ DRL, THEFT DETERRENT SYSTEM
W/O DRL, THEFT DETERRENT SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, hatchback (2 of 2) -> LIGHT CONTROL TURN SWITCH SWITCH HEADLIGHT DIMMER SWITCH ASSEMBLY
