Toyota Yaris II facelift (2009-2012) front passenger's side door lock control switch Wiring diagram
This page shows the only wiring diagram for the component.front passenger's side door lock control switch, which is found in the car Toyota Yaris II facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's side door lock control switch (1 of 1)
5 6 PNK PNK WIRE
BACK DOOR COURTESY SWITCH (HATCHBACK) (BASE OF BACK DOOR)
BLK WIRE
BLU WIRE
BRN WIRE
DOOR LOCK CONTROL SWITCH
DRIVER'S SIDE DOOR LOCK ASSEMBLY (DRIVER'S DOOR)
DRIVER'S SIDE DOOR LOCK CONTROL SWITCH (SEDAN, W/O POWER WINDOW)
FRONT PASSENGER'S SIDE DOOR LOCK ASSEMBLY (FRONT PASSENGER'S DOOR)
FRONT PASSENGER'S SIDE DOOR LOCK CONTROL SWITCH
GRN WIRE
GRY WIRE
J/B 5 (LEFT KICK PANEL)
J/B 6 (RIGHT KICK PANEL)
LEFT REAR DOOR LOCK ASSEMBLY (LEFT REAR DOOR)
LOCK
LT BLU WIRE
LT GRN WIRE
LUGGAGE DOOR LOCK ASSEMBLY (SEDAN, 4 DOOR) (BASE OF REAR DOOR)
ORG/ WIRE
PNK WIRE
POWER WINDOW MASTER SWITCH (W/ POWER WINDOW)
RIGHT REAR DOOR LOCK ASSEMBLY (RIGHT REAR DOOR)
SEDAN HATCHBACK
UNLOCK
W/O REAR POWER WINDOW W/ REAR POWER WINDOW
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Forced entry circuit (2 of 2) -> FRONT PASSENGER'S SIDE DOOR LOCK CONTROL SWITCH
