Toyota Yaris II facelift (2009-2012) cruise engine control controls system system Wiring diagram
This page shows the only wiring diagram for the component.cruise engine control controls system system, which is found in the car Toyota Yaris II facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cruise engine control controls system system (1 of 1)
10 28 2 (SEDAN W/O VSC) (HATCHBACK W/O VSC) (W/ VSC)
4 3 2 +B LL LR
BLK WIRE
BRN WIRE
CENTER STOP LAMP
COMBINATION METER
CRUISE ENGINE CONTROL CONTROLS SYSTEM SYSTEM
FLASH RELAY
GAUGE FUSE
GRN WIRE
GRY WIRE
HATCHBACK
HAZARD WARNING SIGNAL SWITCH
HEAD OFF TAIL
HEADLAMP DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES ENGINE ROOM R/B HAZ FUSE (LEFT SIDE OF ENGINE COMPT)
HOT AT ALL TIMES INSTRUMENT PANEL J/B STOP FUSE (LEFT SIDE OF DASH)
HOT IN ON OR START
J/B 6 (HATCHBACK: RIGHT
J/B 6 (HATCHBACK: RIGHT KICK PANEL)
KICK PANEL)
LEFT LICENSE PLATE LAMP
LEFT REAR COMBIN- ATION LAMP
LEFT TURN IND
LH RH
LICENSE PLATE TAIL STOP LAMP
LIGHT CONTROL SWITCH
LT GRN WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT LICENSE PLATE LAMP
RIGHT REAR COMBINATION LAMP STOP TAIL
RIGHT TURN IND
SEDAN
SEDAN HATCHBACK
SEDAN LED TYPE
SEDAN LED TYPE HATCHBACK
SEDAN SEDAN BULB TYPE
STOP LAMP SWITCH (BRAKE PEDAL ASSEMBLY)
STP STP
TAIL IND (CANADA)
TURN
TURN SIGNAL SWITCH
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> CRUISE ENGINE CONTROL CONTROLS SYSTEM SYSTEM
