Exterior lamps circuit for Toyota Yaris DJ/DL (2016-2020)

BLK WIRE BLU WIRE BRAKE ACTUATOR ASSEMBLY CAN I/F CENTER STOP LIGHT ASSEMBLY COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM ECU- IG 1 FUSE ECU-B 2 FUSE ENGINE ROOM J/B ENGINE ROOM R/B GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START HOT W/ INSTRUMENT PANEL J/B LED DRIVER LEFT LEFT "C" PILLAR) LEFT LICENSE PLATE LIGHT ASSEMBLY LEFT REAR COMBINATION LIGHT ASSEMBLY LT BLU WIRE LT GRN WIRE MET FUSE PNK WIRE RED WIRE RIGHT RIGHT LICENSE PLATE LIGHT ASSEMBLY RIGHT REAR COMBINATION LIGHT ASSEMBLY STOP STOP FUSE STOP LIGHT SWITCH ASSEMBLY STP RELAY TAIL/SIDE MARKER TURN TURN IND VIO WIRE W/ PRE-COLLISION SYSTEM W/O PRE-COLLISION SYSTEM WHT WIRE WHT/BLK WIRE YEL WIRE

ACC FUSE ALT FUSE BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ECU- IG 1 FUSE EXCEPT PROJECTOR HEADLIGHT PROJECTOR HEADLIGHT IF EQUIPPED FUSIBLE LINK BLOCK ASSEMBLY GRN WIRE HAZARD SWITCH HEADLIGHT DIMMER SWITCH ASSEMBLY HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START INSTRUMENT PANEL J/B J/B 7 J/B 8 LEFT LEFT HEADLIGHT ASSEMBLY LIGHT CONTROL SWITCH LT BLU WIRE LT GRN WIRE MAIN BODY ECU PARKING PNK WIRE RED WIRE RIGHT RIGHT HEADLIGHT ASSEMBLY SIDE MARKER TAIL TAIL 2 FUSE TAIL RELAY TELLTALE LIGHT ASSEMBLY TURN TURN SWITCH WHT WIRE WHT/BLK WIRE YEL WIRE
