Car Wiring Diagrams for Defoggers circuit for Toyota Yaris DJ/DL (2016-2020)

A/C FUSE BLK WIRE BLU WIRE CIRCUIT COMPUTER DATA LINES SYSTEM DEF FUSE DEF RELAY ENGINE ROOM R/B GRN WIRE HEATER CONTROL SUB ASSEMBLY 2 HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT PANEL J/B LEFT "C" PILLAR) LEFT OUTER REAR VIEW MIRROR ASSEMBLY MIRROR HEATER NOISE FILTER (REAR WINDOW DEFOGGER) REAR WINDOW DEFOGGER (BACK DOOR GLASS) REAR WINDOW DEFOGGER SWITCH RED WIRE RIGHT OUTER REAR VIEW MIRROR ASSEMBLY TIMER VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
