Toyota Yaris DJ/DL (2016-2020) computer data lines, mirrors, sound, shift interlock systems Wiring diagram
This page shows the only wiring diagram for the component.computer data lines, mirrors, sound, shift interlock systems, which is found in the car Toyota Yaris DJ/DL (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram computer data lines, mirrors, sound, shift interlock systems (1 of 1)
A/C FUSE
ACC FUSE
ACC RELAY
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
CIG FUSE
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES, MIRRORS, SOUND, SHIFT INTERLOCK SYSTEMS
DEFOGGER, AIR CONDITIONING SYSTEMS
ECU- IG 1 FUSE
ECU-IG 2 FUSE
ELECTRONIC POWER STEERING SYSTEM
EXTERIOR LIGHTS, COOLING FANS, AIR CONDITIONING, ANTI-LOCK BRAKES SYSTEMS
FROM INSTRUMENT PANEL J/B (DIAGRAM 3 OF 3)
FROM TAIL RELAY (DIAGRAM 3 OF 3)
GAUGE FUSE
GRN WIRE
GRY WIRE
IGNITION OR STARTER SWITCH ASSEMBLY
INSTRUMENT PANEL J/B
J/B 7
LOCK
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
ON OFF
P/W RELAY
PNK WIRE
POWER OUTLET SOCKET
STARTING/ CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS, SHIFT INTERLOCK SYSTEMS
TO ENGINE ROOM J/B (DIAGRAM 3 OF 3)
VIO WIRE
WARNING SYSTEMS
WASHER FUSE
WHT WIRE
WHT/BLK WIRE
WIPER FUSE
WIPER RR FUSE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit (2 of 3) -> COMPUTER DATA LINES, MIRRORS, SOUND, SHIFT INTERLOCK SYSTEMS
