Car Wiring Diagrams for Charging circuit for Toyota Venza I facelift (2012-2017)

3.5L ALT ALT FUSE ALT-S FUSE BATTERY BLK WIRE BLU WIRE BRN WIRE CHARGE IND COMBINATION METER ASSEMBLY DRIVE IC DRIVER SIDE J/B ENGINE ROOM J/B ENGINE ROOM R/B GAUGE 1 FUSE GAUGE 2 FUSE GENERATOR ASSEMBLY HOT IN ON OR START LT GRN WIRE MAIN FUSIBLE LINK MICRO- PROCESSOR PNK WIRE POWER SUPPLY CIRCUIT RED WIRE RIGHT END OF DASH) STARTING CIRCUIT WHT WIRE YEL WIRE
