Toyota Venza I facelift (2012-2017) p detection switch wiring diagram
This page shows the only wiring diagram for the component.p detection switch, which is found in the car Toyota Venza I facelift (2012-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
p detection switch wiring diagram (1 of 1)
3.5L 2.7L
BLK WIRE
BLU WIRE
CAN (+)
COMPUTER DATA LINES SYSTEM
DRIVER SIDE J/B
ECU-IG 2 FUSE
GAUGE 1 FUSE
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN RUN OR ACC
KEY INTERLOCK SOLENOID (W/O SMART KEY SYSTEM) (STEERING COLUMN)
KLS+
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
P DETECTION SWITCH
PARK/NEUTRAL POSITION SWITCH ASSEMBLY
PNK WIRE
POWER MANAGEMENT CONTROL ECU
RED WIRE
SHIFT LOCK CONTROL ECU SUB-ASSEMBLY
SHIFT LOCK FUSE
SHIFT LOCK SOLENOID
SLS+
STOP FUSE
STOP LIGHT SWITCH ASSEMBLY
TOP OF TRANSMISSION)
VIO WIRE
W/ MEMORY
W/ SMART KEY SYSTEM W/O SMART KEY SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> P DETECTION SWITCH
