Toyota Venza I facelift (2012-2017) left outer rearview mirror assembly Wiring diagram
This page shows the only wiring diagram for the component.left outer rearview mirror assembly, which is found in the car Toyota Venza I facelift (2012-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left outer rearview mirror assembly (1 of 1)
3.5L 2.7L
ALT FUSE
AUTOMATIC LIGHT CONTROL SENSOR
BACKUP
BACKUP LAMPS CIRCUIT
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY
BRK RELAY
BRN WIRE
CENTER STOP LIGHT ASSEMBLY
CLTB
CLTE
CLTS
CRUISE CONTROL SYSTEM
DOME FUSE
DOOR 1 FUSE
ENGINE ROOM J/B
ENGINE ROOM R/B
GRN WIRE
GRY WIRE
HAZ FUSE
HOT AT ALL TIMES
LEFT OUTER MIRROR CONTROL ECU
LEFT OUTER REARVIEW MIRROR ASSEMBLY
LEFT REAR COMBINATION LIGHT ASSEMBLY
LEFT REAR LIGHT ASSEMBLY
LICENSE PLATE LIGHT ASSEMBLY
LT BLU WIRE
LT GRN WIRE
PNK WIRE
POWER MANAGEMENT CONTROL ECU
RED WIRE
RIGHT OUTER MIRROR CONTROL ECU
RIGHT OUTER REARVIEW MIRROR ASSEMBLY
RIGHT REAR COMBINATION LIGHT ASSEMBLY
RIGHT REAR LIGHT ASSEMBLY
SHIFT LOCK CONTROL ECU SUB-ASSEMBLY
STOP
STOP LIGHT ASSEMBLY SWITCH
TAIL
TRANSMISSION CONTROL ECU ASSEMBLY
TRN+
TRNI
TURN
TURN STOP
TURN TAIL
VIO WIRE
W/ MEMORY
W/O MEMORY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> LEFT OUTER REARVIEW MIRROR ASSEMBLY
