Toyota Venza I facelift (2012-2017) left front lumbar support forward, back motor assembly Wiring diagrams

BLK WIRE BLU WIRE BRN WIRE DOWN DRIVER'S SIDE J/B ASSEMBLY FRONT FRONT VERTICAL GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT LUMBAR POWER SEAT SWITCH LEFT FRONT LUMBAR SUPPORT FORWARD, BACK MOTOR ASSEMBLY LEFT FRONT POWER SEAT LIFT POSITION MOTOR ASSEMBLY LEFT FRONT POWER SEAT RECLINING POSITION MOTOR ASSEMBLY LEFT FRONT POWER SEAT SLIDE POSITION MOTOR ASSEMBLY LEFT FRONT POWER SEAT SWITCH LEFT FRONT POWER SEAT VERTICAL POSITION MOTOR ASSEMBLY LIFTER LT BLU WIRE LT GRN WIRE P/SEAT FUSE PNK WIRE REAR RECLINING RED WIRE SLIDE WHT WIRE WHT/BLK WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE BUCKLE SWITCH CANN CANP COMPUTER DATA LINES SYSTEM CPUB DBCL DRIVER'S SIDE J/B ECU- IG 1 FUSE ECU-B FUSE ENGINE ROOM R/B FRONT FRV- GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START LEFT FRONT LUMBAR POWER SEAT SWITCH LEFT FRONT LUMBAR SUPPORT FORWARD, BACK MOTOR ASSEMBLY LEFT FRONT POWER SEAT LIFT POSITION MOTOR ASSEMBLY LEFT FRONT POWER SEAT RECLINING POSITION MOTOR ASSEMBLY LEFT FRONT POWER SEAT SIDE POSITION MOTOR ASSEMBLY LEFT FRONT POWER SEAT VERTICAL POSITION MOTOR ASSEMBLY LEFT FRONT SEAT INNER BELT ASSEMBLY LEFT OUTER MIRROR CONTROL ECU LFT- LT BLU WIRE LT GRN WIRE MRY MSWE O/P GND P/SEAT FUSE PNK LFT- WIRE PNK WIRE POSITION CONTROL ECU, SWITCH ASSEMBLY RCL- RDC REAR RED WIRE SEAT MEMORY SWITCH SET- SGND SIG SLD SLIDE SENSOR SSRS PNK PVCC WIRE SYSB VCC VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
