Passenger power seat circuit for Toyota Venza I (2008-2012)
Passenger power seat circuit
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER SIDE J/B
GRN WIRE
HOT AT ALL TIMES
LT GRN WIRE
P/SEAT FUSE
PNK WIRE
RCLF RCLR
RECLINING
RED WIRE
RIGHT FRONT LUMBAR POWER SEAT SWITCH
RIGHT FRONT LUMBAR SUPPORT FORWARD, BACK MOTOR ASSEMBLY
RIGHT FRONT POWER SEAT RECLINING POSITION MOTOR ASSEMBLY (RIGHT SEAT BACK)
RIGHT FRONT POWER SEAT SLIDE POSITION MOTOR ASSEMBLY (LEFT SIDE OF RIGHT SEAT)
RIGHT FRONT POWER SEAT SWITCH
SLDF SLDR
SLIDE
WHT WIRE
