Car Wiring Diagrams for Electrochromic mirror circuit for Toyota Venza I (2008-2012)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 IG 12 13 10 CANH CANL SMR BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER SIDE J/B ECU- IG 1 FUSE HEADLIGHT SWIVEL ECU ASSEMBLY (W/AUTOMATIC HIGH BEAM SYSTEM) (CENTER OF DASH) HOT IN ON OR START INNER REAR VIEW MIRROR ASSEMBLY LIN RED WIRE SGND MIC+ MIC- SOUND, NAVIGATION SYSTEMS WHT WIRE WHT/BLK WIRE YEL WIRE
